Ricoh M047 - Friction Pad; Paper Feed Roller

Paper Feed
M347 2 SM
4. Remove the paper feed unit [B] ( x 5).
 You must remove eight screws in total to remove the paper feed unit [B].
1.1.2 PAPER FEED ROLLER
1. Pull out the paper tray.
2. Paper feed roller [A] (move the lever [B] to the left.)
1.1.3 FRICTION PAD
1. Pull out the paper tray.
2. Friction pad [A]
