3.2 SERVICE MAINTENANCE
To enable the machine for maintenance by the service technician, the meter-charge mode
must be set to "1: Yes" with SP5930-001.
The table below shows the PM items serviced by the service technician.
After completing a PM procedure, reset the PM counter for the replaced part with SP7-804.
 7-804-2: Transfer roller
 7-804-3: Paper feed roller
 7-804-4: Fusing unit.
3.2.1 MAIN
Symbol keys: C: Clean/ R: Replace/ L: Lubricate/ I: Inspect
Item 90K EM Quantity Remarks
Paper Feed
Paper Feed Roller R C 1 Clean with water
Friction Pad R C 1 Clean with water
Registration Roller C C 1 Clean with water
Bottom Plate Pad C C 1 Clean with water
Around the Drum
Transfer Roller R 1
Fusing Unit and Paper Exit
Hot Roller R 1
Pressure Roller R 1
Hot Roller Strippers R 5
Fusing Thermistor R C 1
Clean with alcohol if
necessary.
Bushings - Hot Roller R 2
