SP Tables
M047 3-18 SM Appendix
SP3-xxx: Process
3910
Ab Chrg Thermist
[0 to 2 / 0 / 1 /step]
Displays the result of the charge thermister check (temperature) monitored
by the loop back connector.
0: Normal
1: Low temperature limit
2: High temperature limit
3920
Density Adjust
3920 1
Density (1)
[-6 to 3 / 0 / 1 /step]
Adjusts the image density level in 120.8 mm/sec. line speed.
+3: Darkest/ -6: Lightest
3920 2
Density (2)
[-6 to 3 / 0 / 1 /step]
Adjusts the image density level in 161.4 mm/sec. line speed.
+3: Darkest/ -6: Lightest
3923
WasteTonerLimiter
[0 or 1 / 1 /-]
Turns on or off the waste toner limiter. The waste toner limiter is executed
by the threshold time of the PCU rotation.
0: No (Off), 1: Yes (On)
