User Maintenance
M047 3-1 SM
Preventive
Maintenance
3. PREVENTIVE MAINTENANCE
3.1 USER MAINTENANCE
The customer can do all PM items with the Maintenance Kit.
Meter-charge mode must be set to "disabled" (engine SP mode 5930).
Cross-reference: "Engine service mode" in the Appendices.
The Operation panel shows "Replace Maintenance Kit" when the PM counter gets to 90K.
After the user replaces the fusing unit in the maintenance kit, the machine automatically
resets the PM counter.
Item Quantity Remarks
Fusing unit 1
Transfer roller 1
Paper feed roller 3 For standard and optional tray(s)
Friction pad 3 For standard and optional tray(s)
PSU Fan Filter 1
