Installation Requirements
SM 2-2 M047
2.1.3 MACHINE SPACE REQUIREMENT
Place the machine near the power source, providing the clearance as shown below:
A: Over 10 cm (4 inches)
B: Over 10 cm (4 inches)
C: Over 10 cm (4 inches)
D: Over 10 cm (4 inches)
2.1.4 POWER SUPPLY
Make sure the plug is firmly inserted in the outlet.
Avoid multi-wiring.
Be sure to ground the machine.
Input voltage level
120 volts, 60 Hz: More than 10 A
220-240 volts, 50 Hz/60Hz: More than 6 A
Permissible voltage Fluctuation: ±10 %
Do not set anything on the power cord
