SP Tables
M047 3-16 SM Appendix
SP2-xxx: Drum
2001
Charge Rol Bias
Adjusts the voltage applied to the charge roller for printing.
2001 1 Charge (1)
[1000 to 2000 / –1650V / 5V step] DFU
2001 2 Charge (2)
[1000 to 2000 / –1675V / 5V step] DFU
2112
Mainscan Mag
Adjusts the main scan magnification.
2112 1 Mainscan (1)
[-0.5% to 0.5% / 0 / 0.1% step]
2112 2 Mainscan (2)
[-0.5% to 0.5% / 0 / 0.1% step]
2113
Subscan Mag
Adjusts the sub scan magnification.
2113 1 Subscan (1)
[-0.5% to 0.5% / 0 / 0.1% step]
2113 2 Subscan (2)
[-0.5% to 0.5% / 0 / 0.1% step]
2201
Developer Bias
Adjusts the development bias for printing.
2201 1 Developer (1)
[200 to 800 / 700V / 10V step] DFU
2201 2 Developer (2)
[200 to 800 / 750V / 10V step] DFU
2213
Toner End Count
[50 to 200 / 200 / 50 sheets/step]
Adjusts the number of prints the machine can make after it detects toner
near-end.
