Ricoh M047 - By-Pass Feed Roller

By-pass Feed
SM 4-34 M047
4.8.2 BY-PASS FEED ROLLER
1. By-pass feed unit ( p.4-33)
2. By-pass feed upper cover [A].
3. Slide the by-pass feed roller holders [A] to the both edges (
x 1 each).
4. Slide the by-pass feed roller [A] to the left, and then remove it.
