Ricoh M047 - Exit Sensor; Inverter Motor

Electrical Component
G806 4 SM
1.2.3 EXIT SENSOR
1. Open the upper cover.
2. Exit sensor (hooks,
x 1)
1.2.4 INVERTER MOTOR
1. Left Cover ( p.1)
2. Inverter motor [A] (2 timing belts,
x 1 x, gear x 1)
 Remove the motor bracket before removing the inverter motor.
