SP Tables
SM Appendix 3-35 M047
Appendix: SP
Mode Tables
0: Paper not detected, 1: Paper detected
5803 41 Dplx Exit Sensor
Duplex exit sensor;
0: Paper not detected, 1: Paper detected
5803 42 Dplx Turn Sensor
Duplex inverter sensor;
0: Paper not detected, 1: Paper detected
5804
Output check
Turns on electrical components individually for test purposes.
NOTE: SP Modes other than those listed in this table, are not used in the
machine.
5804 1 Main Motor: L
5804 2 Main Motor: H
5804 3 Middle Clutch
5804 4 Tray1 Clutch
5804 5 Tray2 Clutch
5804 6 Regist Clutch
5804 7 Bypass Solenoid
5804 8 Fan High
5804 9 LD1 Compulsion
5804 10 LD2 Compulsion
5804 11 LD1+2 Compulsion
5804 12 Polygon Motor: L
5804 13 Polygon Motor: H
5804 16 Fuser Fuse Cut
5804 17 QL
To Next Page
