SP Tables
M047 3-54 SM Appendix
5840
IEEE 802.11
006
Channel max
Sets the maximum range of the bandwidth for the wireless LAN. This
bandwidth setting varies for different countries.
[1 to 14 / 11 (NA), 13 (EU), 14 (JPN) / 1]
JPN: 1 to 14, NA: 1 to 11, EU: 1 to 13
007
Channel min
Sets the minimum range of the bandwidth for operation of the wireless LAN.
This bandwidth setting varies for different countries.
[1 to 14 / 1 / 1]
JPN: 1 to 14, NA: 1 to 11, EU: 1 to 13
008
Transmission speed
[0 x 00 to 0 x FF / 0 x FF to Auto / -]
0 x FF to Auto [Default]
0 x 11 - 55M Fix
0 x 10 - 48M Fix
0 x 0F - 36M Fix
0 x 0E - 18M Fix
0 x 0D - 12M Fix
0 x 0B - 9M Fix
0 x 0A - 6M Fix
0 x 07 - 11M Fix
0 x 05 - 5.5M Fix
0 x 08 - 1M Fix
0 x 13 - 0 x FE (reserved)
0 x 12 - 72M (reserved)
0 x 09 - 22M (reserved)
011
WEP Key Select
Selects the WEP key.
Bit 1 and 0
00: Key1, 01: Key2 (Reserved),
10: Key3 (Reserved), 11: Key4(Reserved)
This SP is displayed only when the IEEE802.11 card is installed.
