3.3.8 Antenna
The x-Messenger comes together with the EXM-ANT 3 meters adhesive antenna. The location of
installation must be taken into account and the right antenna has to be selected to ensure reliable
connection with the network.
Following antennas is are also available for use:
A B C D
A. Penta-band GSM Antenna
B. EXM-ANT(standard accessory with x-Messenger CPU)
C. The antenna with magnetic base
D. T shape antenna
Note
The Penta-band GSM Antenna is not suitable for installation inside a control panel (shielding).
3.4 Structure & dimension
1. Standard EXM-12 series CPU
A. With LCD panel model
