Rievtech x-Messenger Series - Square Boot; Sin Cos

366
6.5.60 Square Boot
Short Description:
This function is used to calculate the square root of the number present as an input with accuracy to two
decimal points.
Connection
Description
Input Validation
Function validation input. Until this input is activated, the function remains inert.
Validation is active implicitly if it has not been connected.
Input Calculation
input
The value must be between 0 and 32767.
Output Calculation
output
this input is used to choose the input channel to apply to the output.
Operation:
Example: for X = 20000 => Root of X = 141.42. The value read as an output of the function is 14142.
If used as an input, the number is negative and the result is 0.
Performance:
The calculation is accurate to 0.01 either way.
6.5.61 Sin Cos
Short Description
