The states of the outputs are displayed with ON and OFF.
Chapter 6 Configuring & Software-customized mode
Users who are familiar with the logic boxes of Boolean algebra can use the customized mode. In fact
customized mode adapts the function block programming way. eSmsConfig is available as a programming
package for the PC. This mode provides many features, for example:

A graphic interface for offline creation of your circuit program by means of Function
Block Diagram (function chart)
 Simulation of your circuit program on the PC
 Generating and printing of an overview chart for the circuit program
 Saving a backup of the circuit program on the hard drive or other media
 Easy configuration of blocks
 Transferring the circuit program
–
from the x-Messenger to the PC and
–
from the PC to x-Messenger

Setting the TOD
1. Online test: Display of status changes and process variables of x-Messenger in RUN
mode:
–
Status of a digital I/O, shift register bits and cursor keys
–
The values of all analog I/Os
–
The results of all blocks
–
The current values (including the times) of selected blocks
–
Change the output(the input pin of the output cannot be connected) status via
eSmsConfig with customized mode
 Starting and stopping circuit program execution via the PC (RUN, STOP).
The x-Messenger alternative
As you can see, eSmsConfig represents an alternative to conventional engineering
methods:
