Rules for connecting blocks
The following rules apply to the connection of blocks:
1. You can connect a single input to multiple outputs.
2. You cannot connect multiple inputs to a single output.
You cannot interconnect I/O in the same path of a circuit program. Recursion is not permitted. Interconnect
a flag or output if necessary.
Special function blocks also have green "connectors". These do not represent connecting pins, but are used
instead for assigning the parameter settings.
Analog I/O cannot be connected to digital I/O.
6.9.2.4 Delete Function Block or Delete Link
When you put some needless block in program interface or link some default ones, you need to
delete them as follows:
1. Pitch on module or link to delete with mouse.
2. Press “Delete” in the keyboard, or click right button of the mouse, select option
“Delete” in the menu, then you can delete the module or link.
6.10 Simulation Running
eSmsConfig.exe could edit function diagram, and perform function of simulation operation.
After you finish the edit, you can start the function of simulation operation, to
examine program to see if it performs your control logic or not.
Operation Method:
1.Click “Simulation” under the menu “Tools” with left button of the mouse . It’s time to start
program of simulation, or click “ ” in the simulation toolbar with mouse, and it also can open
simulation operation interface. It shows as Fig. 11.9.
