Rievtech x-Messenger Series - And

208
NAND with edge evaluation
OR
NOR
(Not OR)
XOR
(exclusive OR)
NOT
(negation, inverter)
BOOLEAN FUNCTION
BOOLEAN FUNCTION
6.3.1 AND
(Symbol in x-Messenger)
The output of an AND function is only 1 if all inputs are 1, i.e. when they are closed.
A block input that is not used (x) is assigned: x = 1.
Logic table of the AND block:
Input1
Input2
Input 3
Input 4
Output
0
0
0
0
0
0
0
0
1
0
0
0
1
0
0
0
0
1
1
0
0
1
0
0
0
0
1
0
1
0
