6.5.43 Analog filter
Short Description
Analog Inputs
Analog Outputs
Analog Flags
The block number of a function with analog output
Sn (Number of samples): determines how many analog values are sampled within the
program cycles that are determined by the set number of samples. x-Messenger
samples an analog value within every program cycle. The number of program cycles is
equal to the set number of samples.
Possible settings:
8, 16, 32, 64, 128, 256
AQ outputs an average value of the analog input Ax over the current number of
samples, and it is set or reset depending on the analog input and the number of
samples.
* Analog inputs: 0 to 10 V corresponds with 0 to 1000 (internal value).
