(Reset) input. Reset has priority over Trg
Output Q
Q switches on only after Write function had been executed
correctly.
Description of Memory write block’s property dialog box :
1. File name
Place where you can set the name of the file used to save the registers’ data
2. Record title
Below is an example in the “OUTPUT.TXT”
The above range circled in red is just pre-set contents in the “Record title” of the Memory write block’s
property dialog box.
