Basic Wireless Network Based On AP (Infrastructure)
Infrastructure: it’s also called basic network.It built by AP and many STAs which join in.
The characters of network of this type are that AP is the center, and all communication between
STAs is transmitted through the AP. The figure following shows such type of networking.
External Antenna
If user select external antenna, HF-A11 modules must be connected to the 2.4G antenna
according to IEEE 802.11b/g/n standards.
The antenna parameters required as follows:
Transparent Transmission Mode
