Rievtech x-Messenger Series - Page 439

439
Extension model
EXM-E-8AC-R
EXM-E-8DC-DA-R
Inputs
4 digital
4 digital
of which can be used in
analog mode
none
4 (0 to 10V)
Input/supply voltage
110-240V AC
12-24V DC
Permissible range
with signal “0”
with signal “1”
Input current
85 ... 265 V AC
100 ... 253 V DC
max. 40 V AC 0.03
mA
min. 79 V AC, 0.08
mA
10.8 V ... 28.8 V DC
max. 3 V DC,1mA
min. 8 V DC,1.5 mA
Outputs
4 relays
4 relays
Continuous current
10 A with resistive
load;
2 A with inductive
load
10 A with resistive
load;
2 A with inductive
load
Short-circuit protection
External fuse required
Switching frequency
2 Hz with resistive
load;
0.5 Hz with
inductive load
2 Hz with resistive
load;
0.5 Hz with inductive
load
2 Hz
Connection cables
2 x 1.5 mm² or 1 x 2.5 mm²
Ambient temperature
-20 ºC to + 55 ºC
Storage temperature
– 40 ºC to + 70 ºC
Degree of protection
IP20
Certification
CE
Mounting
On 35 mm standard mounting rail, 4 MW, or wall-mounting
Dimensions
(W X H X D) 48 x 90 x 64 mm
