441
Extension model
EXM-E-RS485
Inputs
of which can be used in analog
mode
none
Input/supply voltage
12-24V DC
Permissible range
with signal “0”
with signal “1”
Input current
Isolated 485 converter, used to
bring out the terminals of RS485
port built-in EXM-12 series CPU
for connection with third party
devices.
Outputs
Continuous current
Short-circuit protection
External fuse required
Connection cables
2 x 1.5 mm² or 1 x 2.5 mm²
Ambient temperature
-20 ºC to + 55 ºC
(LCD display /refresh reaction speed shall be slow at -20 ºC , response time :3s)
Storage temperature
– 40 ºC to + 70 ºC
Degree of protection
IP20
Certification
CE
Mounting
On 35 mm standard mounting rail, 4 MW, or wall-mounting
Dimensions
(W X H X D) 48 x 90 x 64 mm
Accessories
EXM-CB-B
Extended connection cable between x-Messenger CPU &Extension modules, 3-meter standard
length
Program Copier
(ELC-Copier)
Program Copier can be used for mass program production from CPU to CPU.
Data-logger
(ELC-MEMORY)
Data-logger is a data logging devices with a mini-SD card for x-Messenger’s 12-points CPUs,
specific production or process data(such as I/O status, analog values, register values etc)can be
saved in SD card of Data-logger to either read it with a PC or evaluate it from the SD card at the
work station. It’s good for data analysis. SD card capacity up to 2GB.
ELC-RS232
RS232 communication cable between PC and x-Messenger CPUs
ELC-USB
USB communication cable between PC and x-Messenger CPUs
