Appendix D Module Diagnostic Assembly
2. Diagnostic IO-Link Master Assembly A
- Instance ID = 0x8008 (32,776)
- Size = 232 bytes
Follow the information in Table 38
to add each member.
3. Diagnostic IO-Link Master Assembly B
- Instance ID = 0x8009 (32,777)
- Size = 232 bytes
Follow the information in Table 39
to add each member.
4. Diagnostic IO-Link Master Assembly C
- Instance ID = 0x800A (32,778)
- Size = 232 bytes
Follow the information in Table 40
to add each member.
Table 38 - Diagnostic Assembly Instance 32776
Name Data Type Byte Valid Values
ChannelMode00 SINT 1 The operating mode of the channel.
ChannelMode01 SINT 1 The operating mode of the channel.
ChannelMode02 SINT 1 The operating mode of the channel.
ChannelMode03 SINT 1 The operating mode of the channel.
Pad DINT 4 This member acts as padding to ensure byte alignment. It can be renamed.
AB:5000_IOLM_Channel:D:0 Ch00 User-defined 56
User-defined data type for AB:5000_IOLM_Channel:D:0, see Table 44
.
AB:5000_IOLM_Channel:D:0 Ch01 User-defined 56
AB:5000_IOLM_Channel:D:0 Ch02 User-defined 56
AB:5000_IOLM_Channel:D:0 Ch03 User-defined 56
Table 39 - Diagnostic Assembly Instance 32777
Name Data Type Byte Valid Values
ChannelMode04 SINT 1 The operating mode of the channel.
ChannelMode05 SINT 1 The operating mode of the channel.
ChannelMode06 SINT 1 The operating mode of the channel.
ChannelMode07 SINT 1 The operating mode of the channel.
Pad DINT 4 This member acts as padding to ensure byte alignment. It can be renamed.
AB:5000_IOLM_Channel:D:0 Ch04 User-defined 56
User-defined data type for AB:5000_IOLM_Channel:D:0, see Table 44
.
AB:5000_IOLM_Channel:D:0 Ch05 User-defined 56
AB:5000_IOLM_Channel:D:0 Ch06 User-defined 56
AB:5000_IOLM_Channel:D:0 Ch07 User-defined 56
Table 40 - Diagnostic Assembly Instance 32778
Name Data Type Byte Valid Values
ChannelMode08 SINT 1 The operating mode of the channel.
ChannelMode09 SINT 1 The operating mode of the channel.
ChannelMode10 SINT 1 The operating mode of the channel.
ChannelMode11 SINT 1 The operating mode of the channel.
Pad DINT 4 This member acts as padding to ensure byte alignment. It can be renamed.
AB:5000_IOLM_Channel:D:0 Ch08 User-defined 56
User-defined type for AB:5000_IOLM_Channel:D:0, see Table 44
.
AB:5000_IOLM_Channel:D:0 Ch09 User-defined 56
AB:5000_IOLM_Channel:D:0 Ch10 User-defined 56
AB:5000_IOLM_Channel:D:0 Ch11 User-defined 56
