Appendix D Module Diagnostic Assembly
5. Diagnostic IO-Link Master Assembly D
- Instance ID = 0x800B (32,779)
- Size = 232 bytes
Follow the information in Table 41
to add each member.
6. Diagnostic Counters Ethernet Adapter Assembly
- Instance ID = 0x303 (771)
- Size = 28 bytes
Follow the information in Table 42
to add each member.
Table 41 - Diagnostic Assembly Instance 32779
Name Data Type Byte Valid Values
ChannelMode12 SINT 1 The operating mode of the channel.
ChannelMode13 SINT 1 The operating mode of the channel.
ChannelMode14 SINT 1 The operating mode of the channel.
ChannelMode15 SINT 1 The operating mode of the channel.
Pad DINT 4 This member acts as padding to ensure byte alignment. It can be renamed.
AB:5000_IOLM_Channel:D:0 Ch12 User-defined 56
User-defined type for AB:5000_IOLM_Channel:D:0, see Table 44
.
AB:5000_IOLM_Channel:D:0 Ch13 User-defined 56
AB:5000_IOLM_Channel:D:0 Ch14 User-defined 56
AB:5000_IOLM_Channel:D:0 Ch15 User-defined 56
Table 42 - Diagnostic Assembly Instance 771
Name Data Type Byte Valid Values
RunMode BOOL
1
0 = Idle
1 = Run mode
InfoBits_Pad1 BOOL This member acts as padding to ensure byte alignment. It can be renamed.
DiagnosticActive BOOL
0 = No diagnostics active
1 = One or more diagnostics are active or the prognostics threshold is reached
InfoBits_Pad3 BOOL This member acts as padding to ensure byte alignment. It can be renamed.
InfoBits_Pad4 BOOL This member acts as padding to ensure byte alignment. It can be renamed.
InfoBits_Pad5 BOOL This member acts as padding to ensure byte alignment. It can be renamed.
InfoBits_Pad6 BOOL This member acts as padding to ensure byte alignment. It can be renamed.
InfoBits_Pad7 BOOL This member acts as padding to ensure byte alignment. It can be renamed.
DiagnosticSequenceCount SINT 1
-128…+127
The value of 0 is skipped except during module power-up.
TCPConnections INT 2 Total number of active TCP connections.
CIPConnections INT 2 Total number of active CIP connections.
CIPLostPackets DINT 4 Total number of lost CIP packets.
CIPTimeouts DINT 4 Total number of connection timeouts that have occurred.
HMIPacketRate DINT 4 The packet rate between the module and HMI.
IOPacketRate DINT 4 The packet rate to and from the module.
EthernetErrors DINT 4 Total number of Ethernet errors.
CPUUtilization INT 2 Total CPU load.
