4 Application Examples
This chapter includes various examples that illustrate how to use firewall rules to man-
age network traffic, set up specific features, services and VPN connections, and con-
figure decoders to block communication containing certain file types or keywords.
4.1 Firewall Rule Examples
Firewall rules can be configured to manage the traffic on your network and protect
users from viruses, malware and other common exploits.
The following examples provide sample firewall rules for various scenarios. Each
example includes an overview of the rules necessary for the scenario and the order in
which rules should be applied to ensure most efficient rule processing.
These examples assume a network layout similar to that in the figure below.
Figure 4-1: Sample network zones.
For more information on creating firewall rules, see Chapter 3.3, "Firewall Rule Set-
tings", on page 22.
Before you proceed, make sure the license module updates have been installed as
described under Chapter 3.4.1.3, "Updates", on page 33.
