User Interface
R&S
®
GP-E/GP-S
19User Manual v16.2.1 ─ 01
are not displayed if you close an editor panel by clicking the button in the upper right
corner of the panel, however).
The PDF version of the gateprotect Firewall User Manual is also available from the
logon page. Click on "User Manual" to access the file.
3.1.2 Navigation Pane
The navigation pane (2) is on the left side of the web interface and consists of two
parts. The links in the left navigation bar provide access to the gateprotect Firewall set-
tings. The item list bar on the right is used to display information on the current desktop
configuration.
Both bars contain a search field at the top which can filter the lists to help you quickly
find menus or items. Each search field works for the bar it is part of only. As you type in
the search field, gateprotect Firewall reduces the lists to show only those menus or
items that contain the characters you are typing.
The information displayed in the item list bar depends on, firstly, the menu item
selected in the navigation bar and, secondly, how much information you desire to be
displayed. You can unfold more detailed information by clicking
or reduce the
amount of information presented by clicking in the upper right corner of this pane.
To view the complete list of menus or items again, reset the search by clicking in the
search field.
See Chapter 3.4, "Menu Reference", on page 29 for details on the options available
in each view.
3.1.3 Desktop
The desktop (3) fills the main portion of the screen below the header area and to the
right of the navigation pane. The information displayed here depends on the item
selected in the navigation pane or on the desktop.
Web Interface Components
