Field Description
"Destination Zone" From the drop-down list, select the zone in which the destination host (the inter-
nal IP address) is located.
"Destination Host" From the drop-down list with all available IP addresses for the destination zone,
select the custom host to which the traffic should be forwarded (the internal IP
address).
The buttons at the bottom right of the editor panel depend on whether you add a new
IP forwarding rule or edit an existing rule. For a newly configured IP forwarding rule,
click "Create" to add the rule to the list of available IP forwarding rules or "Cancel" to
reject the creation of the new rule. To edit an existing rule, click "Save" to store the
reconfigured rule or "Reset" to discard your changes. You can click "Close" to shut the
editor panel as long as no changes have been made on it.
Click " Activate" in the toolbar at the top of the desktop to apply your configuration
changes.
3.4.4.7 Policy Based Routes
Policy-based routing can be used to specify which traffic should go out of which inter-
face or interface group of the WAN zone to a certain custom host or network.
Policy Based Routes Overview
Navigate to "WAN > Policy Based Routes" to display the list of policy-based routes that
are currently defined on the system.
The plus button
above the filter settings allows you to add new policy-based routes.
The "Filter Settings" allow you to narrow the list of results in the table to display only
entries that include a certain search string. You can filter the contents by choosing the
required options in the drop-down menu and/or entering search strings in the respec-
tive input fields. Click "Apply" to apply the selected filter options. The list of policy-
based routes is adjusted to reflect your filter results. Click "Reset" to delete the
selected filter options and display an unfiltered view of the list of policy-based routes.
The table columns of the policy-based routes list display whether the policy-based
route is active or not, the "Name" of the route and the selectors that can be used to
define which traffic should go out of which interface or interface group of the WAN
zone. The buttons in the right column allow you to view and adjust the settings for an
existing policy-based route, create a route based on a copy of an existing policy-based
route or delete a route from the system.
For further information, see Chapter 3.2, "Icons and Buttons", on page 21.
To close the "Policy Based Routes" panel, click
in the upper right corner of the
panel.
Policy Based Routes Settings
Under "WAN > Policy Based Routes" , you can add a new or edit an existing policy-
based route.
