Field Description
"Month of Year" Select one or more months of the year to associate with the profile.
"Day of Week" Select one or more days of the week to associate with the profile.
"Day of Month" Select one or more days of the month to associate with the profile.
The buttons at the bottom right of the editor panel depend on whether you add a new
time profile or edit an existing profile. For a newly configured time profile, click "Create"
to add the profile to the list of available time profiles or "Cancel" to discard your
changes. To edit an existing time profile, click "Save" to store the reconfigured profile
or "Reset" to discard your changes. You can click "Close" to shut the editor panel as
long as no changes have been made on it.
The time profiles defined here are available for use in custom firewall rules as descri-
bed under Chapter 3.3, "Firewall Rule Settings", on page 22. If a time profile is associ-
ated with a firewall rule and selected in the item list bar, the respective connection is
highlighted on the desktop. If you select a node on the desktop, the time profile associ-
ated with this node is highlighted in the item list bar.
Click "
Activate" in the toolbar of the desktop to apply your configuration changes if
the edited time profile is already associated with a firewall rule.
3.4.2 Network
Use the " Network" settings to create and edit firewall rules and to set up static
routes, remote syslog servers, an SSL proxy, High Availability, Forensic Traffic Cap-
ture, and NAT rules.
3.4.2.1 Firewall Rules
Use these settings to define the firewall rules which are used to manage network traf-
fic. For more detailed information on firewall rules, see Chapter 3.3, "Firewall Rule Set-
tings", on page 22.
Navigate to "Network > Firewall Rules" to display the list of firewall rules that are cur-
rently defined on the system.
The plus button above the filter settings allows you to add new firewall rules.
The settings dialog for firewall rules opens. For more detailed information on how to
create firewall rules, see Chapter 3.3, "Firewall Rule Settings", on page 22.
The "Filter Settings" allow you to narrow the list of firewall rules to display only rules
that include a certain search string. You can filter the contents by choosing the
required options in the drop-down lists and/or entering search strings in the respective
input fields. Click "Apply" to make use of the selected filter options. The list of firewall
rules is adjusted to reflect your filter results. Click "Reset" to delete the selected filter
options and display an unfiltered view of the list of firewall rules.
The table columns of the firewall rules list display the following information:
