Field Description
"Zone" From the drop-down list, select the zone to which this port forwarding rule
should apply.
"Source Port Range" Enter a unique single port (for example 800) or a port range using a hyphen '-'
character (for example 800-810) as the source.
"Target Port Range" Enter a unique single port (for example 900) or a port range using a hyphen '-'
character (for example 900-910) as the destination.
"Target IP" Enter a valid IP address from within the selected zone.
"Protocols" Select the protocols ( "TCP" / "UDP" ) for which the rule should be used. At
least one protocol has to be selected.
The buttons at the bottom right of the editor panel depend on whether you add a new
port forwarding rule or edit an existing rule. For a newly configured port forwarding rule,
click "Create" to add the rule to the list of available port forwarding rules or "Cancel" to
reject the creation of the new rule. To edit an existing rule, click "Save" to store the
reconfigured rule or "Reset" to discard your changes. You can click "Close" to shut the
editor panel as long as no changes have been made on it.
Click " Activate" in the toolbar at the top of the desktop to apply your configuration
changes.
3.4.4.6 IP Forwardings
gateprotect Firewall supports "IP Forwardings" , which can be used to publish services
provided by an internal server to the Internet without assigning a public IP address to
this server. The server's internal IP address is transparently mapped to a public IP
address.
IP forwarding rules redirect all incoming traffic for the WAN zone's public IP address to
an internal IP address.
For IP forwarding, NAT must be enabled in the WAN zone settings. For further infor-
mation, see "WAN Zone Settings" on page 85.
IP forwarding can only work if the WAN IP address is configured as a static IP address
(no DHCP/PPPoE). For further information, see "Multi-WAN Settings" on page 86.
IP Forwarding Overview
Navigate to "WAN > IP Forwardings" to display the list of IP forwarding rules that are
currently defined on the system in the item list bar.
In the expanded view, the columns of the table display the "Name" and the "State"
(active or not) of the IP forwarding rule. The buttons in the last column allow you to
view and adjust the settings for an existing IP forwarding rule, create a rule based on a
copy of an existing IP forwarding rule or delete a rule from the system.
