User Interface
R&S
®
GP-E/GP-S
35User Manual v16.2.1 ─ 01
Creating a Backup
1. Navigate to "Firewall > Backup > Local Backups" .
2.
Click the plus button (Create a new backup) in the item list bar header.
3. On the "Backup" panel that opens, enter a "Custom name" for the backup. This
name has to be unique and may consist of 3 to 25 characters (allowed are letters
of the English alphabet, integers, dashes, underscores and dots). If no custom
name is provided, the system automatically assigns a name.
4. Click "Create" to add the new backup to the list of available backups or "Cancel" to
reject the creation of the backup.
Use this function, for example, to reload a configuration after a system update or to
transfer a configuration to a second (secondary) firewall for a High Availability solution.
For further information, see Chapter 3.4.2.5, "High Availability", on page 60.
Importing a Backup
1. Navigate to "Firewall > Backup > Local Backups" .
2.
Click the
(Import backup) button in the item list bar header.
3. Select a backup file to transfer from your computer or click "Cancel" to reject the
transfer of the backup.
4. If the import is successful, the backup is added to the list of available backups so
you can restore this configuration later. Click "Close" to shut the confirmation win-
dow.
If High Availability is enabled, it is not possible to import a backup on the master sys-
tem. An error message is displayed that asks you to disable High Availability first.
Viewing the Details of a Backup
1. Navigate to "Firewall > Backup > Local Backups" .
2.
Click the (View backup details) button next to the backup you would like to view
the details of.
3. The "Backup" panel that opens displays the name and the timestamp of the crea-
tion of the backup.
4. Click "Close" to exit the "Backup" panel.
Exporting a Backup
1. Navigate to "Firewall > Backup > Local Backups" .
