In the expanded view, the columns of the table display the "Name" of the DynDNS
account, indicate whether the account is "Enabled" and show the "Server Type" . The
buttons in the last column allow you to view and adjust the settings for an existing
DynDNS account, create an account based on a copy of an existing DynDNS account
or delete an account from the system.
For further information, see Chapter 3.2, "Icons and Buttons", on page 21.
DynDNS Accounts Settings
The "DynDNS Accounts" settings allow you to define custom accounts for the WAN
zone in general.
Under "WAN > DynDNS Accounts" , you can add a new or edit an existing DynDNS
account.
The "DynDNS Accounts" settings allow you to configure the following elements:
Field Description
"On" / "Off" A slider switch indicates whether the DynDNS account is active ( "On" ) or inac-
tive ( "Off" ). By clicking the slider switch, you can toggle the state of the
DynDNS account. A new DynDNS account is enabled by default.
"Server Type" From the drop-down list of supported DynDNS services, select the type of
server to be used.
"Server Address" Optional: Enter the address of the server if your DynDNS provider requires the
definition of a different server address.
"User Name" Enter the user name with which your account is registered with the DynDNS
provider.
"Password" Enter the password with which your account is registered with the DynDNS pro-
vider.
"Show Password" Optional: Select this checkbox to verify the password.
"WAN Interfaces" Optional: Select the WAN interface to be used for this DynDNS service and
then click "Add" . Several interfaces can be added. You can delete or change
the position of each single entry in the list by clicking the appropriate button
next to an entry. gateprotect Firewall will communicate the IP of the first opera-
tional interface to the DynDNS service.
"Host Name" DynDNS services provide a domain name entry under their authority. So a reg-
istered host always has the suffix of the service provider (for example
yourname.dynamicdns.org). Enter the complete host name in this input
field.
"Wildcards" Optional: Select this checkbox to activate the possibility to use wildcards in host
names if you plan to use subdomains of your DynDNS account (for example,
*.yourname.dynamicdns.org will resolve for any domains ending with
yourname.dynamicdns.org).
The buttons at the bottom right of the editor panel depend on whether you add a new
DynDNS account or edit an existing account. For a newly configured account, click
"Create" to add the account to the list of available DynDNS accounts or "Cancel" to dis-
card your changes. To edit an existing account, click "Save" to store the reconfigured
account or "Reset" to discard your changes. You can click "Close" to shut the editor
panel as long as no changes have been made on it.
