Roland VersaEXPRESS RF-640 - Performing the Initial Adjustment

2
Basic Operation
Loading Media
29

Align the front edge of the media with the location shown in the gure.
Conrm that the right edge of the media is aligned with the guideline.

Lower the loading lever (front) to secure the media in place.
Align here
