MASTER STC
USER MANUAL
10
SPEEDY MEASUREMENTS ?
The MASTER STC is a really complete instrument: you will be able to perform a wide variety of
measurements on an extensive range of frequencies and of signal kinds.
This user manual will guide you throughout all the functionalities of your meter.
Should you need a brief shortcut to manage a specific kind of signal, please refer to the content of
this paragraph.
3 ONE TOUCH AND GO
3.1 ANALOGUE TV, DIGITAL (COFDM) TV AND QAM (CATV)
SIGNALS
1 Connect the signal cable to the F-type connector [U] on the meter.
2 Press once and release the PLAN
[1] key. Highlight the item TELEVISION and
select the proper Country Channel Plan.
3 Press once and release the MEAS
[5] key.
4 Rotate the encoder [D] to navigate the selected Country Channel Plan. The ROVER
AUTODISCOVERY ® feature will automatically detect the signal type (analogue, digital,
QAM, …) as well as the related parameters (bandwidth, symbol rate, …) and will
properly tune it.
5 Press and release the MEAS
[5] key to display the various measurements
screens. Each pulse on the MEAS [5] key will display a further measurement screen, on
a round-robin basis.
3.2 ANALOGUE SATELLITE SIGNALS, DIGITAL QPSK & 8PSK
SATELLITE SIGNALS
1 Connect the signal cable to the F-type connector [U] on the meter.
2 Press once and release the PLAN
[1] key. Highlight the item SATELLITE and
select the required Satellite.
3 Press once and release the MEAS
[5] key.
4 Rotate the encoder [D] to surf the various transponders of the selected satellite. The
ROVER AUTODISCOVERY ® feature will automatically detect the signal type
(analogue, digital, …) as well as the related parameters (bandwidth, symbol rate, …) and
will properly tune it.
5 Press and release the MEAS
[5] key to display the various measurements
screens. Each pulse on the MEAS [5] key will display a further measurement screen, on
a round-robin basis.
