MASTER STC
USER MANUAL
17
SatSCR USER:
Using the Standard Navigation Mode, highlight the item SatSCR USER.
and select the
appropriate user. Up to 8 different users can be set up together with their relevant
SCR frequency value.
To manually enter each frequency value, proceed as described at paragraph SatSCR
FREQ at page 17. If the SatSCR USER
item is set to NONE, it won’t be possible to set
up any frequency value.
SatSCR FREQ:
Using the Standard Navigation Mode, highlight the SatSCR USER
item and select the
User whose SCR frequency value has to be set up.
Using the Standard Navigation Mode, highlight the SatSCR FREQ
item and set up the
required frequency value. If the SatSCR USER
item is set to NONE, it won’t be
possible to set any frequency value.
SatSCR CABLE
Using the Standard Navigation Mode, highlight the item SatSCR CABLE. Then press
the encoder [D] knob once and the LCD [C] will display:
The meter will perform the spectrum analysis for each user (from USER N.1 to USER
N.8).
The black-filled spectrum is referred to the currently selected user; the other users’
signals appears as a shape.
Using the Standard Navigation Mode, you can set up the signal level end-of-scale.
8.5 ADVANCED SETTINGS
The patented ROVER Autodiscovery feature is capable to automatically detect the standard
of the tuned signal (analogue TV, DVB-T, DVB-S, QAM, …), the relevant bandwidth as well
as the appropriate Symbol Rate (where applicable). This feature allows the user to navigate
