MASTER STC
USER MANUAL
11
3.3 FM / FM RADIO SIGNALS [87,5 – 108 MHz]
1 Connect the signal cable to the F-type connector [U] on the meter.
2 Press once and release the PLAN
[1] key. Highlight the item MANUAL MEMORY
and select one of the MANU Memory Plans.
3 Press once and release the MEAS
[5] key.
4 Rotate the encoder [D] and select a channel where no signal or an Analogue TV signal
is received.
5 Press and release repeatedly the MEAS
[5] key up to display the main Audio
peak level measurement screen.
6 Using the Standard navigation Mode, highlight the tuned signal type (TV ANALOG / TV
COFDM DVB-T/H) and select select the item FM RADIO.
7 Rotate the encoder [D] and select the desired frequency. The signal level is displayed
and the received audio signal can be listened through the meter built-in loudspeaker
3.4 SPECTRUM ANALYZER FEATURE (ANY FREQUENCY)
1 Connect the signal cable to the F-type connector [U] on the meter.
2 Tune the desired frequency (no matter if TV or Satellite).
3 Press once and release the SPECT
[4] key to display the spectrum of the current
signal.
