MASTER STC
USER MANUAL
68
MEMORY FEATURES FOR SATELLITE SIGNALS
22 CREATING A TRANSPONDER MEMORY PLAN
22.1 MANUALLY CREATING A TRANSPONDER MEMORY PLAN:
MANUMEMORY
Press and release the MANUMEMORY [9] key.
CREATE A BRAND NEW MEMORY PLAN
Using the Standard navigation Mode, highlight the MANUxx item in the LCD top left
corner. Select the memory plan to be created (target memory plan). When the current
target memory plan is void, the LCD displays (top row, right to the MANUxx
item) PR 1;
otherwise, a number greater than 1 will appear to the right hand-side of item PR
.
Using the Standard Navigation Mode, highlight the MANUxx item and then select a void
memory plan.
• Highlight the signal type item displayed on the LCD second row (analogue, digital
DVB-S, digital DSS) and select the required signal type. Then proceed in the same
way with the LNB high/low band and polarization, DISEqC, Local oscillator (L.O.)
and Symbol rate (SR).
• Highlight the frequency value displayed on the LCD top right corner, and select the
desired value. Rotate the encoder [D] quickly to speed up the frequency surfing.
• Highlight the item STORE? AND press the encoder knob [D] to store the selected
transponder.
To add further transponders to the memory plan, highlight the signal type icon and
proceed as described above.
Press once and release the MEAS [5] key to quit this function.
ADDING A FURTHER TRANSPONDER TO AN EXISTING MEMORY PLAN
Using the Standard Navigation Mode, highlight the MANUxx item (MANU 1, MANU 2,
…) in the LCD top left corner, and select the desired memory plan. On the right hand-
side to the highlighted item, the first available memory position (PR…) will be displayed
Should you need To add
a new transponder to the current target memory plan, proceed
as described into the next chapter.
To replace
a transponder previously stored in the current target memory plan:
