NO-OSD-DISPLAY DISTANCE
ADDR MODEL/DATA CONTENT
NTSC PAL
HI8 NOR HI8 NOR D7 D6 D5 D4 D3 D2 D1 D0
Samsung Electronics 4-9
Alignment and Adjustment
0F5 FF - - - ;
0F6 FF - - - ;
0F7 41 41 41 41 ; VSTOP OFFSET AD D/ZOOM
0F8 01 - - - ; Dis_Oaehs_Wa_Gizz: CCD WHITE DEFECT COMPENSATION H STSRT
0F9 F6 F4 F2 F2 ; Dis_Oaehe_Wa_Gizz: CCD WHITE DEFECT COMPENSATION H END
0FA 02 - - - ; Dis_OaeVs_Wa_Gizz: CCD WHITE DEFECT COMPENSATION V STSRT
0FB 77 77 8E 8E ; Dis_OaeVe_Wa_Gizz: CCD WHITE DEFECT COMPENSATION V END
0FC 03 - - - ; SEPIA R #26C
0FD C9 C9 B0 B0 ; #26D
0FE 02 - - - ; SEPIA B #26E
0FF 60 - D0 D0 ; #26F
100 ~ 116 TOP INITIALIED DATA: FIXED
117 02 01 02 01 ;E_SP2ADCK LOWER 4BIT (ADCK PHASE SELECT )
117 ~ 11F TG-INITIALIZED DATA: FIXED
120 04 03 01 03 ; E_DLRG (RG PHASE DELAY )
121 00 03 08 08 ; E_DLSP1(SHP PHASE DELAY )
122 01 0E 00 0F ; E_DLSP2(SHD PHASE DELAY )
123 ~ 1A4 TG-INITIALIZED DATA= FIXED
1A5 ~ 1FE LD/CB BLOCK INITIALIZED DATA= FIXED
1FF ~ 227 KZ(WHITE DEFECT COMPENSATION) BLOCK INITIALIZED DATA FIXED
228 ~ 24B Y PROCESS BLOCK
228 02 - - - ; D RANGE VARIABLE COEFF.(H) :256STANDARD:03 FF TYP.=X2, 512STANDARD:02 00 TYP.X1
229 60 60 60 60 ; D RANGE VARIABLE COEFF.(L)
22A 01 - 0B - ; H_BPF_MAIN_G_MODE(4bit/1bit)(H ENHANCER BPF COEFF.-MSB D4=0:+,1:-)
22B 04 - - - ; H ENHANCER CORE LEVEL(0.5LCB)
22C 0F - - - ; H_YOKUATU(H ENHANCER SUPPRESS LEVEL: 5LSB)
22D 01 01 01 01 ; H ENHANCER NOISE COEFF.(0~8TIMES)
22E 0F - - - ; H ENHANCER HIGH LEVEL COEFF.(0~8TIMES)
22F 1C 18 18 18 ; H ENHANCER COEFF.(0~8TIMES)
230 01 - 01 - ; H_BPF_MAIN_G_MODE(4bit/1bit)
231 00 - - - ; TEST MODE
232 15 - - - ; VENH_LMT (V ENHANCER INPUT LIMIT LEVEL)
233 04 - - - ; HIGH- V ENHANCER CORE LEVEL(0.5LSB)
234 06 - - - ; KV_YOKUATU (HIGH- V ENHANCER SUPPRESS LEVEL)
235 01 01 01 01 ;HIGH- V ENHANCER NOISE COEFF.(0~8 TIMES)
236 0B - - - ;HIGH- V ENHANCER HIGH LEVEL COEFF.(0~8 TIMES)
237 16 14 12 12 ;HIGH- V ENHANCER COEFF.(0~8 TIMES)
238 00 - - - ;TEST MODE
239 13 - - - ;“HENH_HL (HIGH LIGHT H ENHANCER COEFF.);100IRE OVER , H ENHANCER
23A 3F - - - ;GM_IN_LMT (GAMMA INPUT LIMIT); 100IRE = 10HEX
23B 05 - - - ;GM_KNEE (GAMMA KNEE COEFF.); 100IRE OVER, GAMMA CURVE
23C 0F 0D 0F 0F ;Y_GAMMA (GAMMA COEFF.) ; 0~100IRE GAMMA CURVE
23D 00 - - - ;GM_BC (GAMMA BLACK CLIP COEFF.)
23E 08 - - - ;HLENH_CR (HILIGHT ENHANCER CORE LEVEL)
23F 32 34 37 32 ;GAMMA ,BEFORE, SETUP ADJUST”
240 09 - - - ;Y M_F PEDESTAL LEVEL CHANGE ;OFFSET BINARY CODE (NTSC TPY:0E HEX)
241 01 - - - ;Y M_F PEDESTAL LEVEL CHANGE; 1=ADD, 0=SUB.
242 BB - C4 C0 ;FADE_LEV (FADE LEVEL) ;BLACK FADE TYP=C0 hex
243 00 - - - ;Y_WB NEGA = ‘1’ , POSI=’0’
244 10 - 12 - ;HLENH_LM (HILIGHT ENHANCER LIMIT LEVEL)
245 00 - - - ; TEST MODE
246 00 - - - ;NEGA/POSI
