NO-OSD-DISPLAY DISTANCE
ADDR MODEL/DATA CONTENT
NTSC PAL
HI8 NOR HI8 NOR D7 D6 D5 D4 D3 D2 D1 D0
Samsung Electronics4-10
Alignment and Adjustment
247 00 - - - ;“SOLARI_Y (YSIGNAL ART LEVEL); SET, BIT =0 FIX
248 1F - - - ;STATE DATA SETTING MODE
249 00 - - - ;“Y OUTPUT SIGNAL SELECT; 0 =CAMERA MODE ,1 =LINE MODE)
24A 02 01 02 02 ;Y DELAY ADJUST ; CAMEAR MODE : TYP=02 hex (+/-2 CLOCK)
24B 00 - - - ; TEST MODE
24C ~ 26B C PROCESS MATRIX BLOCK DATA: FIXED
26C 03 - 03 03 ;R SETUP (R set) HIGH
26D 53 83 90 8C ;R SETUP (R set) LOW
26E 03 - 03 03 ;B SETUP (B set) HIGH
26F 43 3A 45 2C ;B SETUP (B set) LOW
270 03 - 03 03 ;G SETUP (G set) HIGH
271 36 - 38 40 ;G SETUP (G set) LOW
272 00 - 00 00 ;R GAIN (Kr) HIGH
273 AA A0 B9 C5 ;R GAIN (Kr) LOW
274 01 - 01 01 ;B GAIN (Kb) HIGH
275 70 F3 F0 AE ;B GAIN (Kb) LOW
276 ~ 27F C PROCESS MATRIX BLOCK DATA: FIXED
280 01 - 01 01 ;G r-y,r-g(R-YSIGNAL R-GGAIN) HIGH
281 1A 10 48 2A ;G r-y,r-g(R-YSIGNAL R-GGAIN) LOW
282 00 - 00 00 ;G b-y,b-g(B-YSIGNAL B-GGAIN) HIGH
283 A0 C0 D0 E2 ;G b-y,b-g(B-YSIGNAL B-GGAIN) LOW
284 01 - 01 01 ;G b-y,r-g(B-YSIGNAL R-GGAIN) HIGH; Mc-y =’1’ R-G > 0 AREA GAIN
285 10 03 50 20 ;G b-y,r-g(B-YSIGNAL R-GGAIN) LOW
286 00 01 00 00 ;G b-y,r-g(-) (B-YSIGNAL R-G(-)GAIN) HIGH; ‘’ R-G <0 AREA GAIN
287 11 10 01 24 ;G b-y,r-g(-) (B-YSIGNAL R-G(-)GAIN) LOW”
288 01 - 01 01 ;G r-y,b-g(R-YSIGNAL B-GGAIN) HIGH; Mc-y =’1’ R-G > 0 AREA GAIN”
289 40 4E 68 60 ;“G r-y,b-g(R-YSIGNAL B-GGAIN) LOW”
28A 01 - 01 01 ;“G r-y,b-g(-) (R-YSIGNAL B-G(-)GAIN) HIGH; ‘’ R-G <0 AREA GAIN”
28B 20 25 40 2D ;“G r-y,b-g(-) (R-YSIGNAL B-G(-)GAIN) LOW”
28C ~ 2A1 C PROCESS MATRIX BLOCK DATA: FIXED
2A2 ~ 2B6 AF INITIALIZED BLOCK FIXED
2B7 ~ 2E1 AE INITIALIZED BLOCK FIXED
2C5 07 05 08 05 ;HCOUNT_2 ( AREA 6 START -> 32PIXEL )
2C6 0D 09 0D 09 ;
2C7 13 0E 15 0E ;HCOUNT_4 ( AREA 6 STOP -> 32PIXEL)
2C8 1A 11 1A 11 ;
2C9 1A 11 1A 11 ;HCOUNT_6 ( EFFECTIVE PIXEL STOP -> 32PIXEL)
2D6 05 - 06 06 ;VERTICAL AE WINDOW(V1)
2D7 05 - 06 06 ;VERTICAL AE WINDOW(V2)
2D8 0E 0E 11 11 ;VERTICAL AE WINDOW(V3)
2D9 0E 0E 11 11 ;VERTICAL AE WINDOW(V4)
2DA 0E 0E 11 11 ;VERTICAL AE WINDOW(V5)
2E2 ~ 302 AWB INITIALIZED BLOCK FIXED
2E2 20 20 21 21 ;OFSMG_N (OFFSET Mg-G)
2E3 22 22 23 23 ;OFSRB_N (OFFSET R-B)
2E4 00 - - - ;CW_LEV_G0 (aMGL : G WHITE DETECTIONAREA)
2E5 1C 14 1C 1A ;CW_LEV_M0 (aMGH : Mg WHITE DETECTIONAREA)
2E6 9B A8 A8 A6 ;CW_LEV_B0 (aRBL : B WHITE DETECTIONAREA)
2E7 3F 44 3F 3C ;CW_LEV_R0 (aRBH : R WHITE DETECTIONAREA)
2E8 8A 90 8A 8F ;CB_LEV_G0 (bMGL : G WHITE DETECTIONAREA)
