NO-OSD-DISPLAY DISTANCE
ADDR MODEL/DATA CONTENT
NTSC PAL
HI8 NOR HI8 NOR D7 D6 D5 D4 D3 D2 D1 D0
Samsung Electronics 4-11
Alignment and Adjustment
2E9 0A 10 10 10 ;CB_LEV_M0 (bMGH : Mg WHITE DETECTIONAREA)
2EA 95 A2 A2 A2 ;CB_LEV_B0 (bRBL : B WHITE DETECTIONAREA)
2EB 40 48 38 38 ;CB_LEV_R0 (bRBH : R WHITE DETECTIONAREA)
2EC 03 - - - ;Y_LEV_L0 (LOW LUMINANCE WHITE DETECTIONAREA)
2ED 12 - - - ;Y_LEV_H0 (HIGH LUMINANCE WHITE DETECTIONAREA)
2EE 04 - - - ;OFFSET DEC Mg-G
2EF 02 - - - ;OFFSET DEC R-B
303 ~ 333 DIGITAL ZOOM(DSP) INITIALIZED BLOCK FIXED
334 ~ 37B MOSAIC/MIRROR (DSP) INITIALIZED BLOCK FIXED
37C ~ 385 DISPLAY-TOP INITIALIZED BLOCK FIXED
386 ~ 3B5 SSG INITIALIZED BLOCK FIXED
386 00 - - 02 ;TV_MODE D2,D1=00: NTSC, 10=PAL
387 03 - - - ;HCLR1( SSG_H COUNTER CLEAR1 ;H-START)- HIGH
388 74 74 80 80 ;LOW
389 01 01 01 01 ;HCLR2 ( SSG_H COUNTER CLEAR2 ;H-MIDDLE )- HIGH
38A AD AD B8 B8 ;LOW
38B 00 00 00 00 ;VCLR (SSG_V COUNTER CLEAR( T=H/2) -HIGH
38C 02 02 02 02 ;LOW
38D 02 02 02 02 ;CBLK_V tf ( CBLK V blanking START PHASE)-HIGH
38E 09 09 70 70 ;LOW
38F 2A 2A 33 33 ;CBLK_V tr ( CBLK V blanking END PHASE)
390 00 - - - ;TKEY1_H tr (H DIRECTION TKEY1 START PHASE)-HIGH
391 56 - 5C 65 ;LOW
392 03 - - - ;TKEY1_H tf (H DIRECTION TKEY1 END PHASE)-HIGH
393 16 - - - ;LOW
394 00 - - - ;TKEY2_H tr (H DIRECTION TKEY2 START PHASE)-HIGH
395 5B - 60 6A ;LOW
396 03 - - - ;TKEY2_H tf (H DIRECTION TKEY2 END PHASE)-HIGH
397 11 - - - ;LOW
398 00 - - - ;TKEY1_V tr (V DIRECTION TKEY1 START PHASE)-HIGH
399 20 18 20 1E ;LOW
39A 00 01 01 01 ;TKEY1_V tf (V DIRECTION TKEY1 END PHASE)-HIGH
39B FA 00 30 30 ;LOW
39C 00 - - - ;TKEY2_V tr (V DIRECTION TKEY2 START PHASE)-HIGH
39D 23 1B 23 23 ;LOW
39E 00 - 01 01 ;TKEY2_V tf (V DIRECTION TKEY2 END PHASE)-HIGH
39F F7 FD 2D 2D ;LOW
3A0 43 - - - ;HSYNC tf ( CSYNC PHASE1 ;T=1/fs)
3A1 00 - - - ;HSYNC tr ( CSYNC PHASE2 ;T=1/fs)-HIGH
3A2 87 - - - ;LOW
3A3 66 - - - ;EQ tr ( CSYNC PHASE3 ;T=1/fs)
3A4 22 - - - ;CAMERA MODE(REC); EN_CBLK tf (CBLK H blanking START PHASE, INTERNAL encoder)
3A5 00 - - - ;CAMERA MODE(REC); EN_CBLK tr (CBLK H blanking END PHASE, INTERNAL encoder)-HIGH
3A6 97 97 AD AD ;LOW
3A7 43 - - - ;OSDHD tr ;OSDHDSTARTPHASE(SCBLKSTARTPHASE; OSD)
3A8 00 - - - ;OSDHD rf ;OSDHDENDPHASE( OSD)-HIGH
3A9 87 87 81 81 ;LOW
3AA 25 25 25 25 ;CBLK tr (CBLK blanking STARTPHASE)
3AB 00 - - - ;CBLK tf (CBLK blanking ENDPHASE)-HIGH
3AC D5 D5 D9 E8 ;LOW
3AD 4F 4F 5C 5C ;CAMERA MODE(REC); LCDHD tf ,LCDHD STARTPHASE, LCD
3AE 00 - - - ;CAMERA MODE(REC); LCDHD tr, LCDHD END PHASE, LCD -HIGH
3AF 53 53 60 60 ;LOW
