Samsung Electronics4-14
Alignment and Adjustment
NO-OSD-DISPLAY DISTANCE
ADDR MODEL/DATA CONTENT
NTSC PAL
HI8 NOR HI8 NOR D7 D6 D5 D4 D3 D2 D1 D0
58B ~ 5A2 LTG9( DIS-VD PULSE=CVF MODEL) TIMIMG DATA: FIXED CVF
595 00 00 00 00 ; CVF
596 00 - 00 01 ; CVF
597 02 02 02 02 ; DIS VD- HD FALLING TIMING SETTING-HIGH CVF
598 6A 6A 65 6C ; DIS VD- HD FALLING TIMING SETTING-LOW CVF
5A7 94 - - - ; CVF COM_DC MICOM PIN 28 OUTPUT CVF
5A8 52 - - - ; CVF COM_CRL MICOM PIN 21 OUTPUT CVF
5A9 47 47 47 47 ; #3BF EN_A04_0F H reset -LOW CASIO-LCD-PB CVF-PB
5AA 1B 43 38 43 ; #3AD SSG_A04_DE PB MODE H- START PULSE CASIO-LCD-PB CVF-PB
5AB 00 00 00 00 ; #3AE SSG_A04_DF PB MODE H- END PULSE CASIO-LCD-PB CVF-PB
5AC 3B 47 40 47 ; #3AF SSG_A04_DF PB MODE H- END PULSE CASIO-LCD-PB CVF-PB
5AD ~ 5CD CASIO LCD (CANON MODEL) SETTING
5AD 00 - - - ; #3D3 GAMMA 1 HIGH CASIO-LCD
5AE 3E - - - ; #3D4 GAMMA 1 LOW CASIO-LCD
5AF 2E - - - ; #3DB CONTRAST( 0~4TIMES 1/64 STEP 40hX1 CASIO-LCD
5B0 00 - - - ; #3DC BRIGHT (R) , BRIGHT 0~255 :00h SETTING IS +0 bright ADJUST CASIO-LCD
5B1 00 - - - ; #3DD BRIGHT (G) , BRIGHT 0~255:00h SETTING IS +0 bright ADJUST CASIO-LCD
5B2 00 - - - ; #3DE BRIGHT (B) , BRIGHT 0~255: 00h SETTING IS +0 bright ADJUST CASIO-LCD
5B3 00 - - - ; #3E3 GAMMA 2 HIGH CASIO-LCD
5B4 40 - - - ; #3E4 GAMMA 2 LOW CASIO-LCD
5B5 80 - - - ; #3E5 R GAIN CASIO-LCD
5B6 80 - - - ; #3E6 G GAIN CASIO-LCD
5B7 70 - - - ; #3E7 B GAIN CASIO-LCD
5B8 50 - A9 - ; LCD COM_DCMICOM PIN 28 OUTPUT CASIO-LCD
5B9 60 - 50 - ; LCD COM_CRLMICOM PIN 21 OUTPUT CASIO-LCD
5BA 54 54 54 54 ; STEP R GAIN LCD USER ADJUST CASIO-LCD
5BB 54 54 54 54 ; STEP G GAIN CASIO-LCD
5BC 54 54 54 54 ; STEP B GAIN CASIO-LCD
5BD 55 - - - ; CASIO-LCD
5C0 00 - - - ; #4D7 CAM MODE- VERTICAL CONVERT CASIO-LCD
5C1 1D - 3A - ; #4D8 #4D7~#4D8:COMMAND CASIO-LCD
5C2 00 - - - ; #4D9~4DA,4DB~4DC,4E5~4E6,4E7~4E8 CASIO-LCD
5C3 18 - 1D 1D ; #4D9~4DA,4DB~4DC,4E5~4E6,4E7~4E8 CASIO-LCD
5C4 00 - 00 00 ; #4D7 PB MODE MODE -LCD VERTICAL SIZE SIZE CASIO-LCD
5C5 16 - 2C 16 ; #4D8 ( H SIZE# 690) CASIO-LCD
5C6 00 - 00 00 ; #4D9~4DA,4DB~4DC,4E5~4E6,4E7~4E8 CASIO-LCD
5C7 0D - 11 17 ; #4D9~4DA,4DB~4DC,4E5~4E6,4E7~4E8 CASIO-LCD
5CA 00 00 00 00 ; #4D7 VTR-PB MODE VERTICAL/HORIZENTAL DIRECTION CONVERT CASIO-LCD
5CB 1D - 3A - ; #4D8 CASIO-LCD
5CC 00 - - - ; #4D9~4DA,4DB~4DC,4E5~4E6,4E7~4E8 CASIO-LCD
5CD 0F - 11 15 ; #4D9~4DA,4DB~4DC,4E5~4E6,4E7~4E8 CASIO-LCD
5EC 59 - - - ; K r-y/r-y -HIGH ,gain 4TIMES(0~1023/64) #3C6 CVF
5ED 5A - - - ; K g-y/r-y -HIGH ,gain 4TIMES(0~1023/64) #3C8 CVF
5EE 92 - - - ; K b-y/b-y -HIGH ,gain 4TIMES(0~1023/64) #3CA CVF
5EF 40 - - - K g-y/b-y -HIGH ,gain 4TIMES(0~1023/64) #3CC CVF
5F9 66 - 66 66 ; #4F0 PB MODE CVF
5FA 66 - 66 66 ; #4F6 PB MODE CVF
5FB 71 - 71 71 ; #4FC PB MODE CVF
5FC 71 - 71 71 ; #502 PB MODE CVF
600 ~ 67F DIS REGISTER
600 48 - - - DIS_ON ZOOM_ON LSSC_ON MIRR_ON PIP_ON POWER PIP_MIRR BYPASS
601 8C - - - FRAME STILL1 STILL2 CEDGE_ON APT_ON OSD_ON TRA_ON GAMA_ON
