Samsung Electronics 4-15
Alignment and Adjustment
NO-OSD-DISPLAY DISTANCE
ADDR MODEL/DATA CONTENT
NTSC PAL
HI8 NOR HI8 NOR D7 D6 D5 D4 D3 D2 D1 D0
602 20 00 60 40 DVC PAL HIGH FLD_SEL BIST PN_SEL CUR_HOLD CLEAR
603 00 - - - KX (7:0) HORIZONTAL ZOOM COEFFICENT VALUE
604 00 - - - KY (7:0) VERTICAL ZOOM COEFFICENT VALUE
605 85 5E 83 5E SP_H (7:0) HORIZONTAL START POINT FOR ZOOM
606 11 11 16 14 SP_V (7:0) VERTICAL START POINT FOR ZOOM
607 03 F0 00 00 WIDTH (7:0) HORIZONTAL WIDTH LSB
608 03 01 03 02 X X X X X X WIDTH (9:8) WIDTH MSB
609 F5 F5 22 22 |—— HEIGHT [7:0] VERTICAL HEIGHT LSB ——|
617 65 3D 63 3D |—— OUT_OFF (7:0) FIELD MEMORY1 HORIZONTAL OUTPUT S/P ——|
618 65 3D 63 3D |—— OUT_OFF1 (7:0) FIELD MEMORY1 HORIZONTAL OUTPUT S/P ——|
619 08 08 - - GR_MODE (7:4) INTERNAL IMAGE SELECT MODE |—— OSD_VAL (3:0) ——|
61A 8E 8E 90 8E CLK2_SEL |—— CLK2_SEL (6:0) CLK DELAY ADJUST ——|
61B 00 60 2C 2C S1S2_SEL0 CRCB_SEL0 S1S2_SEL1 CRCB_SEL1 LINE_SEL0 LINE_SEL1 LINE_SEL2 LINE_SEL3
61C 02 02 03 02 OSD_SEL (7:5) |—— HVD_ADJ ——|
673 38 38 38 38 |——PTHRESH (7:0) DIGITAL CLAMP THRESHOLD VALUE FROM MICOM ——|
674 04 04 04 04 |——POFFSET (7:0) DIGITAL CLAMP OFFSET VALUE FROM MICOM ——|
675 03 - - - |——PCMD (7:0) PREPROCESS COMMAND FROM MICOM ——|
676 00 - - - |——PRAMIL (7:0) DEFECT POSITION VALUE(7:0) FROM MICOM ——|
677 00 - - - |——PRAMIM (16:8) DEFECT POSITION VALUE(15:8) FROM MICOM ——|
678 00 - - - X X X X PRAMIM (19:16) DEFECT POSITION FROM MICOM
679 00 - - - X X |—— PRAMA_MI (5:0) LINE MEMORY ADDRESS FROM MICOM ——|
67A 00 - - - ;DIS;FACTOR AT BLC ON CONDTION
67B 00 - - - ;DIS;FACTOR AT BLC ON CONDTION
67C 10 - - - ;DIS;CCD DEFECT COMPENSATION DIGITAL CLAMP LEVEL#674
67D D0 - - - ;DIS; DIS ON AGC AE TARGET DOWN PERCENT
67E F4 - - - ;DIS;WIGHT WHEN DECREASE
67F 00 - - - ;DIS; STEP CONTROL ‘00~88’
680 ~ 7FF VTR PART ADDRESS & DATA [061~067 & 680~7FF ]
690 1B 1B 17 17 ;PB MODE HDIRECTION START PULSE
691 00 - - - ;PB MODE HDIRECTION END PULSE
692 3B 3B 42 42 ;PB MODE HDIRECTION END PULSE
693 07 - - - ;PB MODE(CAM/TG/DEMOD/AD) - STD2
694 FC - - - ;PB MODESTD1
695 03 - - - ;PB MODE(RCON/DISP) - LCD CLOSE(LCD POWER OFF D5 = %%1%%)
696 C3 - - - ; PB MODE
697 00 - - - ;PB MODE(SRAM) - LCD CLOSE(LCD POWER OFF D9 = %%1%%)
698 00 - - - ; PB MODE
699 00 - - - ; PB MODE
69A 01 - - - ; PB MODE
69B 00 - - - ; PB MODE
69C 0F - - - ; PB MODE
69D 14 - - - ; PB MODE
69E 7F - - - ; PB MODE
69F 03 - - - ; PB MODE
6A0 FF - - - ;
6A1 00 07 00 04 ; PB MODE SCK CNT“SCK MASK(NTSC1820fH/3,PAL1824fH/3)
6A2 02 02 03 02 ; PB MODE TG HCYCLE TG: H CYCLE SETTING (T=1/fs) : D11 ~ D9
6A3 8D 5D 8F 5F ; TG HCYCLE TG: H CYCLE SETTING (T=1/fs) : D8 ~ D1
6B0 00 - - - ;BACKUP_EMG_L VCR EEPROM DATA(LITHIUM BACKUP AREA)
6B1 00 - - - ;BACKUP_EMG_H
6B2 00 - - - ;BACKUP_TTLSELDATA
6B3 00 - - - ;BACKUP_TITLEDSPCUSSTATE(DISP_OFF)//SAMSUNG
6B4 00 - - - ;BACKUP_TITLEDSPSTATE(DISP_OFF)//CANON
