Samsung Electronics4-16
Alignment and Adjustment
NO-OSD-DISPLAY DISTANCE
ADDR MODEL/DATA CONTENT
NTSC PAL
HI8 NOR HI8 NOR D7 D6 D5 D4 D3 D2 D1 D0
6B5 00 - - - ;BACKUP_DTIMEDSPSTATE(DISP_OFF)//CANON
6B6 00 - - - ;BACKUP_PAEDATA(AUTO)
6B7 00 - - - ;BACKUP_DSEDATA(AUTO)
6B8 00 - - - ;BACKUP_PBDSEDATA(AUTO)
6B9 11 - - - ;BACKUP_USERBRIGHT
6BA 11 - - - ;BACKUP_USERCOLOR
6BB 0B - - - ;BACKUP_USERVOLUME
6BC 00 - - - ; RESERVE
6BD 00 - - - ; RESERVE
6BE 00 - - - ; RESERVE
6BF 12 - - - ; RESERVE
6C0 00 - - - ;TAPECOUNTER0
6C1 00 - - - ;TAPECOUNTER1
6C2 00 - - - ;TAPECOUNTER2
6C3 00 - - - ;TAPECOUNTER3
6C4 2B - - - ;BACKUP_FLAG0
6C5 07 - - - ;BACKUP_FLAG1
6C6 4D - - - ;BACKUP_FLAG2
6C7 FF - - - ;
6C8 80 - - - ; ;data low
6C9 00 - - - ; ;data high
6CA 80 - - - ; ;data low
6CB 00 - - - ; ;data high
700 20 20 78 78 ;CAM MODE(REC/RECP/STOP) : D1~D8
701 10 - - - ;CAM MODE(REC/RECP/STOP) : D9~D16
702 00 - - - ;CAM MODE(REC/RECP/STOP) : D17~D24
703 00 - - - ;CAM MODE(REC/RECP/STOP) : D25~D32
704 29 - - - ;CAM MODE(REC/RECP/STOP) : D33~D40
705 78 78 78 78 ;CAM MODE(REC/RECP/STOP) : D41~D48
706 88 - - - ;CAM MODE(REC/RECP/STOP) : D49~D56
707 1B - - - ;CAM MODE(REC/RECP/STOP) : D57~D64
708 88 - - - ;CAM MODE(REC/RECP/STOP) : D65~D72
709 C2 - - - ;CAM MODE(REC/RECP/STOP) : D73~D80
70A 00 - - - ;CAM MODE(REC/RECP/STOP) : D81~D88
70B 6A - - - ;CAM MODE(REC/RECP/STOP) : D89~D96
70C 33 33 13 13 ;CAM MODE(REC/RECP/STOP) : D97~D104
70D 1B - - - ;CAM MODE(REC/RECP/STOP) : D105~D112
70E 9F - - - ;CAM MODE(REC/RECP/STOP) : D113~D120
70F 50 - - - ;CAM MODE(REC/RECP/STOP) : D121~D128
710 21 21 79 79 ;NORMALLYPB PB/EDIT-PB : D1~D8
711 16 16 1E 1E ;NORMALLYPB PB/EDIT-PB : D9~D16
712 05 05 1B 1B ;NORMALLYPB PB/EDIT-PB : D17~D24
713 2E - - - ;NORMALLYPB PB/EDIT-PB : D25~D32
714 29 29 27 27 ;NORMALLYPB PB/EDIT-PB : D33~D40
715 25 - - - ;NORMALLYPB PB/EDIT-PB : D41~D48
716 89 89 CA CA ;NORMALLYPB PB/EDIT-PB : D49~D56
717 1C - - - ;NORMALLYPB PB/EDIT-PB : D57~D64
718 80 - - - ;NORMALLYPB PB/EDIT-PB : D65~D72
719 B0 - - - ;NORMALLYPB PB/EDIT-PB : D73~D80
71A 10 - - - ;NORMALLYPB PB/EDIT-PB : D81~D88
71B 10 - - - ;NORMALLYPB PB/EDIT-PB : D89~D96
71C AA AA A9 A9 ;NORMALLYPB PB/EDIT-PB : D97~D104
71D 24 - - - ;NORMALLYPB PB/EDIT-PB : D105~D112
