Samsung Electronics 4-17
Alignment and Adjustment
NO-OSD-DISPLAY DISTANCE
ADDR MODEL/DATA CONTENT
NTSC PAL
HI8 NOR HI8 NOR D7 D6 D5 D4 D3 D2 D1 D0
71E 48 - - - ;NORMALLYPB PB/EDIT-PB : D113~D120
71F 14 - - - ;NORMALLYPB PB/EDIT-PB : D121~D128
720 00 - - - ;NORMALLYPB PB/EDIT-VRPB : D89~D96
721 17 17 1F 1F ;NORMALLYPB STIL/E-STIL : D9~D16
722 18 - - - ;NORMALLYPB STIL/E-STIL : D17~D24
723 2E - - - ;NORMALLYPB STIL/E-STIL : D25~D32
724 2D 2D 2D 2D ;NORMALLYPB STIL/E-STIL : D41~D48
725 00 - - - ;NORMALLYPB STIL/E-STIL : D89~D96
726 1B - - - ;NORMALLYPB STIL/E-STIL : D105~D112
727 2D 2D 2D 2D ;NORMALLYPB CUE/REV/E-CUE/E-REV : D41~D48
728 B0 - - - ;NORMALLYPB CUE/REV/E-CUE/E-REV : D73~D80
745 24 24 7C 7C ;HI8 CAM(REC/RECP/STOP):D1~D8
746 C9 C9 E9 E9 ;HI8 CAM(REC/RECP/STOP):D33~D40
747 78 78 78 78 ;HI8 CAM(REC/RECP/STOP):D41~D48
748 88 - - - ;HI8 CAM(REC/RECP/STOP):D49~D56
749 88 - - - ;HI8 CAM(REC/RECP/STOP):D65~D72
74A C2 - - - ;HI8 CAM(REC/RECP/STOP):D73~D80
74B 03 - - - ;HI8 CAM(REC/RECP/STOP):D81~D88
74C 29 - - - ;HI8 CAM(REC/RECP/STOP):D89~D96
74D 00 - - - ;HI8 CAM(REC/RECP/STOP):D113~D120
74E 50 - - - ;HI8 CAM(REC/RECP/STOP):D121~D128
74F A4 - - - ;HI8-PB(PB/EDIT-PB) : D33~D40
750 45 - - - ;HI8-PB(PB/EDIT-PB):D41~D48 PB ENHANCER
751 89 89 CA CA ;HI8-PB(PB/EDIT-PB):D49~D56
752 80 - - - ;HI8-PB(PB/EDIT-PB):D65~D72
753 D4 - - - ;HI8-PB(PB/EDIT-PB):D73~D80
754 AA AA A9 A9 ;HI8-PB(PB/EDIT-PB):D97~D104
755 49 49 49 49 ;HI8-PB(PB/EDIT-PB):D113~D120
756 0C - - - ;HI8-PB(PB/EDIT-PB):D121~D128
757 0D - - - ;HI8-PB(STILL/E-STILL):D41~D48
758 0D - - - ;HI8-PB(CUE/REV/E-CUE/E-REV):D41~D48
759 B4 - - - ;HI8-PB(CUE/REV/E-CUE/E-REV):D73~D80
776 10 - - - ;NORMALLY AND N/M-PAL PB/SEARCH MODE HI8ME:D113~D120(D90~D91)
777 60 - - - ;TBC OFF : D89~D96: D94~D95
778 1B - - - ;TBC OFF : D105~D112 ; D105~D112
779 5B - - - ;PAL60 TBCOFF : D97~D104 ; D97~D100
77A 5B - - - ;“NORMALLY,M/N_PAL MODE TBC OFF;D97~D104 ; D97~D100”
77B 92 92 12 12 ;LCD OPEN SKEW :D88= 1 SETTING
77C 12 - - - ;“ NOT USED;NORMALLY AND N/M_PAL VRPB,STILL,SEARCH ; D81~D88”
77D 12 - - - ;“ NOT USED;PAL60 VRPB,STILL,SEARCH ; D81~D88”
77E 00 - - - ; NOT USED
77F 00 - - - ; NOT USED
780 80 80 86 86 ;CAM FADE MUTE LEVEL
781 20 20 24 24 ;CAM PEDESTAL LEVEL CAMERA SYNC LEVEL
782 0A - - - ;FMEQ CONTROL LB,HB CURVE AND LIMITER
783 3C - - - ;PB/LB CONVERT COMPENSATION TRAP DEPTH CAMERA B-Y BURST LEVEL
784 59 59 64 64 ;CAM B-Y BURST LEVEL CAMERA R-Y BURST LEVEL
785 80 80 9C 9C ;CAM R-Y BURST LEVEL
786 4A 4A 40 40 ;PB TBC OFF:PEDESTAL LEVEL
787 0E 0E 06 06 ;PB TBC OFF:PB SYNC LEVEL
788 18 - - - ;SYNC SEP&AF ZONE ADD LEVEL
789 38 - - - ;Y AND CAM Y CLIP LEVEL
78A 08 - - - ;CAM SYNC CUT LEVEL
78B 10 - - - ;C RF OUTPUT A/D SETTING
