Samsung SCL770 - Page 93

Samsung Electronics6-10
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
RP32 2007-000052 R-CHIP;10Kohm,1%,1/16W,DA,TP,1608
RP33 2007-000455 R-CHIP;18Kohm,1%,1/16W,DA,TP,1608
RP34 2007-000087 R-CHIP;6.8Kohm,5%,1/16W,DA,TP,1608
RP35 2007-000086 R-CHIP;5.6Kohm,5%,1/16W,DA,TP,1608
RP36 2007-000052 R-CHIP;10Kohm,1%,1/16W,DA,TP,1608
RP37 2007-000455 R-CHIP;18Kohm,1%,1/16W,DA,TP,1608
RP38 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
RP40 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RP41 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RP42 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RP43 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RP44 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RP45 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RP46 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RP47 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RP48 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RP49 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RP50 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
RP51 2007-000287 R-CHIP;100OHM,1%,1/10W,DA,TP,1608
RP52 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
RP53 2007-000863 R-CHIP;4.3OHM,5%,1/10W,DA,TP,2012
RP55 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
RP56 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
RV01 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RV02 2007-000763 R-CHIP;330ohm,1%,1/16W,DA,TP,1608
RV03 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RV04 2007-000763 R-CHIP;330ohm,1%,1/16W,DA,TP,1608
RV05 2007-000763 R-CHIP;330ohm,1%,1/16W,DA,TP,1608
RV06 2007-000099 R-CHIP;62Kohm,5%,1/16W,DA,TP,1608
RV07 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RV12 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RV14 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
RV15 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RV16 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RV17 2007-000086 R-CHIP;5.6Kohm,5%,1/16W,DA,TP,1608
RV18 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
RV19 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
RV20 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
RV21 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
RV24 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
SW601 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S
SW602 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S
SW603 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S
SW606 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S
SW607 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S
T901 AD26-00024A TRANS POWER;CLQ52,W2-PJ,42UH,8P,6~9V,15V
X601 2801-004146 CRYSTAL-SMD;20MHZ,30PPM,SX-3,18PF,30OHM,
X602 2801-000258 CRYSTAL-UNIT;32.768KHz,20ppm,28-AAW,12.5
XP01 2801-004141 CRYSTAL-SMD;28.636MHZ,18PPM,28-ABL,7.0PF
ASSY-CCD BOARD;-,W3-PJ,320K,SONY,KST
CC01 2203-000140 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,1608
CC02 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CC03 2404-000212 C-TA,CHIP;3.3uF,20%,25V,-,TP,3528,-
CC04 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CC05 2404-000212 C-TA,CHIP;3.3uF,20%,25V,-,TP,3528,-
CC06 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CNC01 3711-004241 CONNECTOR-HEADER;BOX,18P,2R,1MM,SMD-A,SN
DC02 0401-001054 DIODE-SWITCHING;KDS160,85V,300mA,SOD-323
QC01 0505-000180 FET-SILICON;2SK1070,N,-,50mA,-,150mW,SOT
RC01 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608
RC02 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
RC03 2007-000125 R-CHIP;3.9Kohm,5%,1/16W,DA,TP,1608
RC05 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RC07 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
ASSY-CCD BOARD;-,W3-PJ,270K,SONY,KST
CC01 2203-000140 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,1608
CC02 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CC03 2404-000212 C-TA,CHIP;3.3uF,20%,25V,-,TP,3528,-
CC04 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CC05 2404-000212 C-TA,CHIP;3.3uF,20%,25V,-,TP,3528,-
CC06 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CNC01 3711-004241 CONNECTOR-HEADER;BOX,18P,2R,1MM,SMD-A,SN
DC02 0401-001054 DIODE-SWITCHING;KDS160,85V,300mA,SOD-323
QC01 0505-000180 FET-SILICON;2SK1070,N,-,50mA,-,150mW,SOT
RC01 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608
RC02 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
RC03 2007-000125 R-CHIP;3.9Kohm,5%,1/16W,DA,TP,1608
RC05 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RC07 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
ADAPTOR BOARD;100/240V,50HZ/60HZ,-,-,-,AA-E6
C10 2203-000455 C-CERAMIC,CHIP;1nF,5%,50V,NP0,TP,2012
C11 2301-001092 C-FILM,MPEF;100nF,20%,275V,BK,18x6x12,15
C12 2401-003302 C-AL;47uF,20%,400V,GP,TP,18X31.5,7.
C13 2401-003046 C-AL;47uF,20%,50V,WT,TP,6.3x11,2.5
C14 2203-000716 C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,2012
C15 2203-000716 C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,2012
C16 2203-000716 C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,2012
C30 2201-000828 C-CERAMIC,DISC;3.3nF,20%,400V,Y5U,TP,15x
C50 2401-000133 C-AL;1000uF,20%,16V,GP,TP,10x20,5
