Samsung Electronics 6-11
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
C51 2401-000037 C-AL;470uF,20%,16V,GP,TP,8x11.5,5
C55 2203-000239 C-CERAMIC,CHIP;0.1nF,5%,50V,NP0,TP,2012
C57 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
C58 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
C59 2203-000938 C-CERAMIC,CHIP;0.47nF,5%,50V,NP0,TP,2012
C61 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
C62 2401-000438 C-AL;10uF,20%,25V,GP,-,5x11,2mm
C63 2203-000455 C-CERAMIC,CHIP;1nF,5%,50V,NP0,TP,2012
CON1 3721-001034 PLUG-AC POWER;2P,-,-,NI
CON2 3711-000900 CONNECTOR-HEADER;BOX,3P,1R,2.5mm,STRAIGH
D10 0402-000137 DIODE-RECTIFIER;1N4007,1000V,1A,DO-41,TP
D11 0402-000137 DIODE-RECTIFIER;1N4007,1000V,1A,DO-41,TP
D12 0402-000137 DIODE-RECTIFIER;1N4007,1000V,1A,DO-41,TP
D13 0402-000137 DIODE-RECTIFIER;1N4007,1000V,1A,DO-41,TP
D14 0402-001041 DIODE-RECTIFIER;ERA22-10,1000V,500mA,MSR
D15 0402-001041 DIODE-RECTIFIER;ERA22-10,1000V,500mA,MSR
D50 0402-001062 DIODE-RECTIFIER;SF10SC9,90V,10A,FTO-220,
D52 0407-000116 DIODE-ARRAY;DAP202K,80V,100mA,CK2-3,SOT-
D53 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT-
D54 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT-
D55 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT-
F10 3601-000207 FUSE-CARTRIDGE;250V,1A,TIME-LAG,GLASS,5.
IC10 1203-002180 IC-PWM CONTROLLER;5M0265,TO220F-4L,4P,39
IC50 AC14-12006D IC;KA431Z,TO-92,TAPING
IC51 AC14-12001K IC;KA324,-,-
J10 AC38-12001U WIRE-JUMPER(H-WRAP);1007#26,120M/M
J11 AC38-12001U WIRE-JUMPER(H-WRAP);1007#26,120M/M
J50 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
J51 AC38-12001U WIRE-JUMPER(H-WRAP);1007#26,120M/M
J52 AC38-12001U WIRE-JUMPER(H-WRAP);1007#26,120M/M
J53 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
J55 AC38-12001U WIRE-JUMPER(H-WRAP);1007#26,120M/M
J56 AC38-12001U WIRE-JUMPER(H-WRAP);1007#26,120M/M
J57 AC38-12001U WIRE-JUMPER(H-WRAP);1007#26,120M/M
J61 AC38-12001U WIRE-JUMPER(H-WRAP);1007#26,120M/M
L50 AC27-12001N COIL-CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,-
LF10 AC27-32001F COIL-LINE FILTER;BSF-2123,20MH,2OHM,ST,-
PC10 0604-000119 PHOTO-COUPLER;TR,200-400%,200mW,DIL-4,ST
Q52 0501-000457 TR-SMALL SIGNAL;MMBT2222A,NPN,350MW,SOT-
R00 2007-000477 R-CHIP;1MOHM,5%,1/10W,DA,TP,2012
R10 2007-000481 R-CHIP;1MOHM,5%,1/8W,DA,TP,3216
R11 2007-000481 R-CHIP;1MOHM,5%,1/8W,DA,TP,3216
R13 2003-000771 R-METAL OXIDE(S);68Kohm,5%,2W,AA,TP,4x12
R14 2007-000598 R-CHIP;22OHM,5%,1/8W,DA,TP,3216
R15 2007-000768 R-CHIP;330OHM,5%,1/8W,DA,TP,3216
R16 2007-000768 R-CHIP;330OHM,5%,1/8W,DA,TP,3216
R17 2007-001212 R-CHIP;82KOHM,5%,1/8W,DA,TP,3216
R18 2007-001212 R-CHIP;82KOHM,5%,1/8W,DA,TP,3216
R19 2007-001212 R-CHIP;82KOHM,5%,1/8W,DA,TP,3216
R20 2007-001212 R-CHIP;82KOHM,5%,1/8W,DA,TP,3216
R21 2001-000374 R-CARBON;15OHM,5%,1/4W,AA,TP,2.4X6.4MM
R30 2001-000739 R-CARBON;4.7MOHM,5%,1/8W,AA,TP,1.8X3.2M
R30 2201-001005 C-CERAMIC,DISC;2.2nF,20%,400V,Y5U,TP,11x
R30A 2201-001005 C-CERAMIC,DISC;2.2nF,20%,400V,Y5U,TP,11x
R50 2007-000472 R-CHIP;1KOHM,5%,1/8W,DA,TP,3216
R51 2007-000472 R-CHIP;1KOHM,5%,1/8W,DA,TP,3216
R53 2007-000868 R-CHIP;4.7KOHM,1%,1/10W,DA,TP,2012
R54 2007-000868 R-CHIP;4.7KOHM,1%,1/10W,DA,TP,2012
R55 2007-000312 R-CHIP;10OHM,5%,1/8W,DA,TP,3216
R57 2007-000938 R-CHIP;47KOHM,1%,1/10W,DA,TP,2012
R58 2007-001205 R-CHIP;82KOHM,1%,1/10W,DA,TP,2012
R59 2007-000868 R-CHIP;4.7KOHM,1%,1/10W,DA,TP,2012
R60 2007-000771 R-CHIP;33KOHM,1%,1/10W,DA,TP,2012
R61 2007-000395 R-CHIP;150KOHM,5%,1/10W,DA,TP,2012
R62 2007-001039 R-CHIP;56KOHM,5%,1/10W,DA,TP,2012
R63 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012
R64 2007-001205 R-CHIP;82KOHM,1%,1/10W,DA,TP,2012
R65 2007-000868 R-CHIP;4.7KOHM,1%,1/10W,DA,TP,2012
R66 2007-000406 R-CHIP;15KOHM,1%,1/10W,DA,TP,2012
R68 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
R70 2007-000546 R-CHIP;20KOHM,5%,1/10W,DA,TP,2012
R71 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
R72 2007-000582 R-CHIP;22KOHM,1%,1/10W,DA,TP,2012
R74 2007-001205 R-CHIP;82KOHM,1%,1/10W,DA,TP,2012
R76 2005-000102 R-WIRE WOUND;0.1ohm,1%,1W,AA,TP,4.5x11mm
R77 2007-000068 R-CHIP;470KOHM,5%,1/10W,DA,TP,2012
R79 2007-001067 R-CHIP;6.8KOHM,1%,1/10W,DA,TP,2012
R80 2007-000477 R-CHIP;1MOHM,5%,1/10W,DA,TP,2012
T10 AD26-00026A TRANS POWER;AA-E6,AA-E6,1.4mH,6P,100~260
VR50 2101-001049 VR-ROTARY;500ohm,-,-,-
REMOCON BOARD;W-PJ,BRM-E1E,EXP,-,-,-,-,-,
CT02 2203-000239 C-CERAMIC,CHIP;0.1nF,5%,50V,NP0,TP,2012
CT03 2203-000239 C-CERAMIC,CHIP;0.1nF,5%,50V,NP0,TP,2012
CT04 2203-000199 C-CERAMIC,CHIP;100nF,+80-20%,50V,Z5U,TP,
ICT01 AD09-00005A IC-MCU;KS51850-H9D,-,REEL,-,-,SOP,-
LDT01 0601-000519 LED-IR;ROUND,5mm,170mW,4V,940nm,-
RT01 2007-000483 R-CHIP;1OHM,5%,1/10W,DA,TP,2012
XT01 2802-000148 RESONATOR-CERAMIC;455KHz,0.4%,BK,7.0x3.5
ASSY-FRONT BOARD;USB,W4-PJ,RMT O,LIGHT O
