Samsung SCL770 - Page 95

Samsung Electronics6-12
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
CN801 AD39-00054A CBF HARNESS;-,-,-,12P,-,-,-,35023,TAPE,5
CN802 3711-000780 CONNECTOR-HEADER;BOX,2P,1R,1.25mm,STRAIG
J801 3722-001441 JACK-PHONE;3P,3.6PI,AG,BLK,-
ASSY-FRONT BOARD;FRONT,W3-PJ,RMT O
CN801 AD39-00054A CBF HARNESS;-,-,-,12P,-,-,-,35023,TAPE,5
CN802 3711-000780 CONNECTOR-HEADER;BOX,2P,1R,1.25mm,STRAIG
ASSY-USB BOARD;W4-PJ,VP-L770,-
CNU01 3708-001650 CONNECTOR-FPC/FFC/PIC;39P,0.3MM,SMD-A,SN
CU01 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CU03 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CU04 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CU06 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CU07 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CU08 2203-000626 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,160
CU10 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CU13 2203-000626 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,160
CU19 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CU20 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CU25 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CU30 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CU32 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CU35 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CU40 2203-000626 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,160
CU41 2203-000626 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,160
CU42 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CU46 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CU47 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CU50 2203-000626 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,160
CU51 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CU52 2203-000626 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,160
CU53 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CU54 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CU56 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CU57 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CU61 2203-000062 C-CERAMIC,CHIP;47nF,+80-20%,50V,Y5V,TP,1
CU62 2203-000062 C-CERAMIC,CHIP;47nF,+80-20%,50V,Y5V,TP,1
CU63 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CU64 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CU65 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CU66 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
ICU01 0904-001638 IC-USC;ARK-8601,16BIT,BGA,96P,13X13MM
ICU02 1204-001573 IC-VIDEO PROCESS;SAA7113H,QFP,44P,393MIL
ICU03 1203-002013 IC-VOLTAGE REGULATOR;62FP3302,SOT-23,3P,
LU01 AC29-32001B FILTER-EMI BEAD;CB321611-TA SB 0.2OH,-,-
LU04 AC29-32001B FILTER-EMI BEAD;CB321611-TA SB 0.2OH,-,-
LU05 AC29-32001B FILTER-EMI BEAD;CB321611-TA SB 0.2OH,-,-
LU06 2703-000363 INDUCTOR-SMD;10uH,5%,2.5x2x1.8mm
LU07 AC29-32001B FILTER-EMI BEAD;CB321611-TA SB 0.2OH,-,-
RU01 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
RU03 2007-000309 R-CHIP;10ohm,5%,1/16W,DA,TP,1608
RU10 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608
RU11 2007-000659 R-CHIP;27ohm,5%,1/16W,DA,TP,1608
RU12 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
RU13 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
RU15 2007-000659 R-CHIP;27ohm,5%,1/16W,DA,TP,1608
RU16 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608
RU20 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
RU28 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RU31 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608
RU32 2007-000121 R-CHIP;820ohm,5%,1/16W,DA,TP,1608
RU51 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
RU52 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
RU53 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
RU60 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
RU61 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
RU62 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
RU63 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
RU64 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
RU65 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
RU66 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
RU67 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
XU01 2801-003907 CRYSTAL-SMD;24.576MHz,50ppm,28-ACO,12pF,
ASSY-REAR BOARD;-,W2-PJ,HI8
CN451 3710-001676 CONNECTOR-SOCKET;38P,2R,0.8mm,SMD-S,SN
CN452 3710-001479 CONNECTOR-SOCKET;14P,2R,1MM,SMD-S,SN
D451 0601-001418 LED;SMD,AMB,-,610nm
Q451 0504-001037 TR-DIGITAL;KRC401,NPN,100MW,4.7K/4.7K,SO
R451 2007-000072 R-CHIP;47ohm,5%,1/16W,DA,TP,1608
R452 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R466 2007-007948 R-CHIP;0.1ohm,1%,0.75W,DA,TP,5025
R472 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R473 2007-000071 R-CHIP;22ohm,5%,1/16W,DA,TP,1608
SW471 3409-001035 SWITCH-DETECTOR;3~5V,50uA~10mA,2,30gf,LE
SW473 3404-001117 SWITCH-TACT;12V,50mA,130gf,8.0x3.7x2.5mm
SW474 3404-001119 SWITCH-TACT;12V,50mA,130gf,6.2x6.2x2.6mm
SW477 3409-001035 SWITCH-DETECTOR;3~5V,50uA~10mA,2,30gf,LE
SW478 3409-001036 SWITCH-DETECTOR;3~5V,50uA~10mA,2,30gf,LE
