Samsung Electronics 6-13

Electrical Parts List

Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark

VR471 2102-001019 VR-SLIDE;10Kohm,30%,1/20W,SLIDE

J452 AD97-01200A ASSY-S-JACK;M1-PJ,-,-

J452 AD97-03052A ASSY-DC JACK;3P,W-PJ,DDSE-0056

J453 3722-001202 JACK-PHONE;7P,3.6PI,AG,YEL,NO

ASSY-EVF BOARD;0.24,W3-PJ,PAL

CE01 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2

CE02 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,

CE03 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,

CE04 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-

CE05 2404-000284 C-TA,CHIP;10uF,20%,16V,-,TP,3528,-

CE07 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2

CE08 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,

CE10 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,

CE11 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,

CE12 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,

CE13 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608,

CE14 2404-000151 C-TA,CHIP;1uF,20%,16V,-,TP,3216,-

CE15 2404-000151 C-TA,CHIP;1uF,20%,16V,-,TP,3216,-

CE16 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2

CE17 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,

CE18 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,

CE19 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,

CE20 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2

CNE01 3708-001680 CONNECTOR-FPC/FFC/PIC;6P,0.5MM,SMD-A,SN

CNE02 3708-001076 CONNECTOR-FPC/FFC/PIC;20P,0.5MM,SMD-S,SN

DE02 0401-001054 DIODE-SWITCHING;KDS160,85V,300mA,SOD-323

ICE01 1003-001373 IC-LCD DRIVER;MCVVQ111FB,LQFP,48P,276MIL

LE01 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm

LE03 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm

LED01 0601-001586 LED;CHIP,WHT,-,470NM

QE02 0501-002310 TR-SMALL SIGNAL;HN1B04FU,PNP/NPN,200mW,U

RE01 2007-001125 R-CHIP;68Kohm,1%,1/16W,DA,TP,1608

RE02 2007-001068 R-CHIP;6.8Kohm,1%,1/16W,DA,TP,1608

RE05 2007-000828 R-CHIP;39Kohm,1%,1/16W,DA,TP,1608

RE06 2007-000772 R-CHIP;33Kohm,1%,1/16W,DA,TP,1608

RE07 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608

RE16 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608

RE17 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608

RE19 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608

RE21 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608

RE22 2007-000342 R-CHIP;120OHM,1%,1/10W,DA,TP,2012

RE24 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608

RE25 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608

RE26 2007-000125 R-CHIP;3.9Kohm,5%,1/16W,DA,TP,1608

RE29 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608

VRE02 2104-001007 VR-SMD;10Kohm,25%,0.15W,TOP

ASSY-FUNCTION BOARD;FUNCTION,W4-PJ,LCD

J470 3811-000389 WIRE-NO SHEATH CU;SPCW,300V,52.4mm,1/0.5

R471 2004-000971 R-METAL;470ohm,1%,1/8W,AA,TP,1.8x3.2mm

R472 2004-000413 R-METAL;18Kohm,1%,1/8W,AA,TP,1.8x3.2mm

R473 2004-000798 R-METAL;33Kohm,1%,1/8W,AA,TP,1.8x3.2mm

R474 2004-000798 R-METAL;33Kohm,1%,1/8W,AA,TP,1.8x3.2mm

R475 2004-000971 R-METAL;470ohm,1%,1/8W,AA,TP,1.8x3.2mm

R476 2004-000413 R-METAL;18Kohm,1%,1/8W,AA,TP,1.8x3.2mm

R477 2004-000798 R-METAL;33Kohm,1%,1/8W,AA,TP,1.8x3.2mm

R478 2004-000798 R-METAL;33Kohm,1%,1/8W,AA,TP,1.8x3.2mm

SW471 3404-001118 SWITCH-TACT;12V DC,50mA,130gf,5x6x4.3mm,

SW472 3404-001118 SWITCH-TACT;12V DC,50mA,130gf,5x6x4.3mm,

SW475 3404-001118 SWITCH-TACT;12V DC,50mA,130gf,5x6x4.3mm,

SW476 3404-001118 SWITCH-TACT;12V DC,50mA,130gf,5x6x4.3mm,

SW477 3404-001118 SWITCH-TACT;12V DC,50mA,130gf,5x6x4.3mm,

SW478 3404-001118 SWITCH-TACT;12V DC,50mA,130gf,5x6x4.3mm,

CN471 3708-001564 CONNECTOR-FPC/FFC/PIC;19P,1mm,ANGLE,SN

CN472 3708-001706 CONNECTOR-FPC/FFC/PIC;6P,1MM,ANGLE,SN

CN473 3711-000826 CONNECTOR-HEADER;BOX,2P,1R,2mm,ANGLE,SN

RM471 AD32-00010A MODULE REMOCON;PIC-2604 SM1,37.9KHz,940n

SW473 3404-001192 SWITCH-TACT;12V DC,50MA,130GF,7.3X6.72X7

SW474 3404-001192 SWITCH-TACT;12V DC,50MA,130GF,7.3X6.72X7

SW479 3409-001127 SWITCH-DETECTOR;5VDC,1mA,1,31gf,LEVER

VR471 2101-001078 VR-ROTARY;1ohm,-,-,TOP

ASSY-FUNCTION BOARD;FUNCTION,W4-PJ,W/O R
