Samsung SCL770 - Page 97

Samsung Electronics6-14
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
CN472 3708-001706 CONNECTOR-FPC/FFC/PIC;6P,1MM,ANGLE,SN
CN473 3711-000826 CONNECTOR-HEADER;BOX,2P,1R,2mm,ANGLE,SN
SW473 3404-001192 SWITCH-TACT;12V DC,50MA,130GF,7.3X6.72X7
SW474 3404-001192 SWITCH-TACT;12V DC,50MA,130GF,7.3X6.72X7
SW479 3409-001127 SWITCH-DETECTOR;5VDC,1mA,1,31gf,LEVER
VR471 2101-001078 VR-ROTARY;1ohm,-,-,TOP
ASSY-LCD BOARD;2.5,W4-PJ,NTSC
CL101 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CL102 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL103 2301-001108 C-FILM,CHIP;22nF,5%,50V,TP,3.2x2.5x1.4,3
CL104 2404-001131 C-TA,CHIP;22UF,10%,10V,GP,TP,3528
CL105 2404-001131 C-TA,CHIP;22UF,10%,10V,GP,TP,3528
CL106 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL107 2404-001131 C-TA,CHIP;22UF,10%,10V,GP,TP,3528
CL108 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL109 2203-005046 C-CERAMIC,CHIP;0.022nF,5%,3kV,NP0,TP,452
CL201 2404-000335 C-TA,CHIP;3.3uF,20%,16V,GP,TP,3216
CL202 2404-000335 C-TA,CHIP;3.3uF,20%,16V,GP,TP,3216
CL203 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CL204 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL205 2404-000157 C-TA,CHIP;1uF,20%,35V,-,TP,3216,-
CL206 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL207 2404-000157 C-TA,CHIP;1uF,20%,35V,-,TP,3216,-
CL208 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL209 2203-000815 C-CERAMIC,CHIP;0.033nF,5%,50V,NP0,TP,160
CL210 2203-000998 C-CERAMIC,CHIP;0.047nF,5%,50V,NP0,TP,160
CL211 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CL212 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CNL101 3708-001603 CONNECTOR-FPC/FFC/PIC;24P,0.5MM,SMD-A,SN
CNL102 3708-001334 CONNECTOR-FPC/FFC/PIC;10P,0.8mm,SMD-A,SN
CNL201 3708-001690 CONNECTOR-FPC/FFC/PIC;28P,0.5MM,SMD-A,SN
DL201 0401-001054 DIODE-SWITCHING;KDS160,85V,300mA,SOD-323
ICL201 0801-002732 IC-CMOS LOGIC;TC7WT126FU,INVERTER,SSOP,8
ICL202 0801-002733 IC-CMOS LOGIC;TC7WT125FU,BUFFER,SSOP,8P,
ICL203 0801-000301 IC-CMOS LOGIC;7W04,INVERTER,SSOP,8P,110M
LL101 2703-000396 INDUCTOR-SMD;10uH,10%,2.5x2x1.8mm
LL102 2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm
LL103 2703-001196 INDUCTOR-SMD;150uH,20%,7x7x3.2mm
LL201 2703-001883 INDUCTOR-SMD;22uH,10%,2.5x2x1.8mm
LL202 2703-000396 INDUCTOR-SMD;10uH,10%,2.5x2x1.8mm
LL203 2703-001883 INDUCTOR-SMD;22uH,10%,2.5x2x1.8mm
LL204 2703-001883 INDUCTOR-SMD;22uH,10%,2.5x2x1.8mm
QL101 0501-002310 TR-SMALL SIGNAL;HN1B04FU,PNP/NPN,200mW,U
QL102 0504-001037 TR-DIGITAL;KRC401,NPN,100MW,4.7K/4.7K,SO
QL103 0502-001182 TR-POWER;KTD1898,NPN,500mW,SOT-89,TP,12
QL104 0502-001182 TR-POWER;KTD1898,NPN,500mW,SOT-89,TP,12
RL101 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RL102 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608
RL103 2007-000116 R-CHIP;120ohm,5%,1/16W,DA,TP,1608
RL104 2007-000516 R-CHIP;2.7Kohm,1%,1/16W,DA,TP,1608
RL105 2007-000516 R-CHIP;2.7Kohm,1%,1/16W,DA,TP,1608
RL106 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
RL201 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
RL202 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
RL203 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
SWL101 3409-001035 SWITCH-DETECTOR;3~5V,50uA~10mA,2,30gf,LE
TL101 AD26-82001C TRANS-INVERTER;12.4X11X3.4,6V,101KHZ,843
