164 Cubis MSA User Manual
Shipping the Balance
Shipping the Balance
If repairs are required, use the original packaging to transport the balance.
To ensure adequate protection for safe shipment, Sartorius products have been
packaged to the extent necessary using environmentally friendly materials.
Only the original packaging provides optimum protection for the equipment.
t Disconnect the device from the power supply.
t Disconnect any data cables from the device.
2
1
3
4
5
6
t Remove all items (such as weights, sensors, etc.) from the weighing chamber.
1) Remove the other side panel
2) Remove the other side panel
3) Remove the upper draft shield panel
4) Remove the weighing pan
5) Remove the pan support
6) Remove the shield plate/draft shield
t On models without a draft shield: press down on the two pan support fasteners.
t Rotate and remove the pan support.
t Place the balance in the lower part of the packaging.
