26 Cubis MSA User Manual
Getting Started
t Attach the display and control unit to the electronics module:
Reattach the two retaining screws.
Open the slot for the connection cable on the electronics module:
t Remove the screws from beneath the electronics module and detach the plate.
Connect the display and control unit to the electronics module:
t Plug in the connection cable.
t Then reattach the plate to the slot.
t Slide the cable that sticks out into the cable channel.
Below-Cell Weighing
A port for a below-cell weighing hook is located on the bottom of the balance.
1. Remove the hook for below-cell weighing from the clip on the bottom of the
balance.
1
