Cubis MSA User Manual 25
Getting Started
Semi-microbalances: Attaching the Display and Control Unit
to the Electronics Module (MSx225.../MSx125... models)
The display and control unit can also be attached to the electronics module if
required for operation.
t Turn over the balance and place it on a soft surface.
Remove the connection cable from the cable channel:
t Remove two screws from beneath the weigh cell and detach the plate.
t Remove the connection cable plug.
t Then reattach the plate to the slot.
t Remove the display and control unit from the weigh cell:
Remove two retaining screws.
t Remove the display and control unit.
