8
MPS4232
Section 1: Specifications
41.15
1.62
38.10
1.50
POWER INPUT: 5-36VDC
ETHERNET: 100baseT AUTO-
CROSSING ETHERNET
CONNECTION
POWER, LINK AND LAN
LED INDICATORS
104.78
4.13
12.70
.50
Px INPUTS 1-16
Px INPUTS 17-32
REFERENCE INPUT
.063"[1.6] O.D. SS
TUBULATION
12.70
.50
REMOVABLE Px INPUT HEADER
AVAILABLE WITH .042" [1.1] (STANDARD) OR .031" [.79] (OPTIONAL) O.D. SS
TUBULATIONS

